Hello,
I'm hoping this will drum up some replies. I'm tumbling head-first into the world of python and ncurses for this, and know very little about both.
To cut a long (and rather boring) story short, I run irssi in a screen session on my poor P166 server. X11-forwarding is not an option as I don't have nor want X11 installed, and it's damn slow even if I did. But one useful feature is using one of the many scripts off of irssi's website, I can get irssi to scrape urls into a text file. "Wooooo, I hear you say".
Well, it is nice. And thanks to network transparency, I am able to tail that logfile via shfs (ssh filesystem, essentially). So then I got to thinking. What's an easy way of displaying the URLs in the file? I remembered a program that ships (often) with mutt -- "urlview". It scans a file for a regexp for URLs and presents a means of selecting them and launching them. Brilliant. Except... it expects a file -- piping to stdin blocks.
Bah! I don't want to hack the source-code, unblocked I/O in C is a headache. So I stumbled across pyurlview [1] a replacement written in Python. It's "ok" and is in a language I can read.
What I'm wanting to do is emulate this:
tail -f ./some_file | pyurlview
Now that doesn't work as-is. So I thought about it a bit, and came up with this little bit of python code (which I hope is the correct "way" to do it):
#! /usr/bin/env python import os,sys while 1: #sys.stdin.fileno() s = sys.stdin.readline() print "Got", s
Which seems to work when one does:
tail -f ./foo | testfile.py
So I thought I'd try and incorporate that idea into the pyurlview script [1] I tried all I might, to no avail. The closest I got was here [2] but that's mangling everything and isn't functioning like in the example I correctly showed above.
So if someone can see the error in logic, do say. Or does anyone know of an existing program that will do what I want? I can use any form of scripting language to do it (awk, ruby, etc) already -- but it's more the curses and non-blocking I/O I'm interested about. Plus, I'd rather not reinvent the wheel, hence battling it out with python. maybe I could use 'multitail' but it's UI sucks for what I am wanting.
Thanks In Advance,
-- Thomas Adam
[1] http://www.dgp.toronto.edu/~mac/code/projects/pyurlview.py
[2] http://edulinux.homeunix.org/~n6tadam/pyurlview-thomas.py
Hi Guru's.
I'm a novice as far as Linux goes and want to attend a course but don't know which flavour to go for or who supplies the best training. From what I have seen my choice should be between RedHat and SuSE..
Any suggestions?
Thanks in advance,
Gavin.
[ cc'd to The Answer Gang ]
Hi, Peter -
On Sat, Apr 09, 2005 at 11:53:18AM +0000, peter.yellman wrote: At http://linuxgazette.net/113/okopnik.html.
When it comes to shell scripting I am a rank novice, but it seemed to me that the passage "if $1 has a length of zero, then the following statements (echo... echo... exit) should be executed" (quotes not mine) should read "if $1 does not have a length of zero, then the following statements (echo... echo... exit) should be executed"
In fact, the article is correct - the
[ -z "$1" ] && { ... }
construct will execute the statement block if $1 is zero length; the "-z" operator returns "true" in that case. You can try it on the command line:
ben@Fenrir:~$ foo=abcdefg # Give some value to 'foo' ben@Fenrir:~$ [ -z "$foo" ] && echo "Foo is empty" ben@Fenrir:~$ foo= # Unset 'foo' ben@Fenrir:~$ [ -z "$foo" ] && echo "Foo is empty" Foo is empty
Thanks for the article,
You're welcome - glad you're enjoying it and thinking about it!
Dan Everhart wrote:
mso@oz.net wrote:
My PyCon 2005 article is up. Newbies will have to bear with some unexplained vocabulary (e.g., Lucerne, which is a full-text indexing system).
In case somebody wants to google, the correct spelling is "Lucene".
No wonder I couldn't find pyLucerne on Google!!!
-- Mike Orr
Hi Gang,
Just a quick note about the difference between "Voice recognition" and "Speech recognition".
Voice recognition means recognizing "The person who is speaking". This is a means of identifying people/persons by listening to their voice. We all do this whenever we use the phone and know who is on the other end as soon as they start talking.
Speech recognition means recognizing the words being spoken.
Voice recognition tools are used to identify people as part of access security systems.
Speech recognition tools (Dragon Naturally Speaking, ViaVoice) are used to "speak" into a computer microphone and have that computer understand what words you said. Currently Naturally Speaking seems to hold the edge in recognition accuracy. This can vary from person to person.
Janine's articles, [issue 113] Voice recognition shorthand and the birth of Weblish and [issue 87] Linux-Based Voice Recognition are actually about Speech recognition, not voice recognition.
-- Jeff Kinz, Emergent Research, Hudson, MA. (A former Speech Recognition software developer)
Thanks for clarifying the distinction, Jeff; we'll pass this on to our readers. I suspect that the common usage isn't likely to change much as a result - but, to misquote Larry Wall, I do occasionally struggle feebly against ignorance, and I admire other people's efforts in that direction as well. -- Ben
Hi, I am using debian unstable with firefox 1.0.2, I try to use the http://linuxgazette.net/cgi-bin/TWDT.pdb and put in the issue number. but it always d/l issue 113 no matter what I put in. I want to d/l the older issues in palmdoc format, how do I do it? Thanks
[Ben] Hi, Louis -
Well, being The Nice Guy that I am , I've just tweaked the chunk of CGI that generates that file to be a bit more flexible; what you're asking for is now available. You can grab any past issue that contains a TWDT.html in PalmDoc format by going to
http://linuxgazette.net/cgi-bin/TWDT.pdb?issue=NAME
where NAME is the name of the issue. Do note, however, that
- Not all of the past LG issues have a TWDT.html (which is what's used to generate the PDB doc.)
- Issues before #100 are actually called "issueXX", where 'XX' is a two-digit issue number (i.e., leading zeros for low numbers.)
To make it simpler, you can use any sort of a bogus string for NAME, and you'll get a list of all issues with links that will return a PDB for that issue. I hope that helps.
...making Linux just a little more fun! |
By Jim Dennis, Jason Creighton, Chris G, Karl-Heinz, and... (meet the Gang) ... the Editors of Linux Gazette... and You! |
We have guidelines for asking and answering questions. Linux questions only, please.
We make no guarantees about answers, but you can be anonymous on request.
See also: The Answer Gang's
Knowledge Base
and the LG
Search Engine
Greetings, and welcome to summertime in the world of
We're seeing a drop in the number of good questions though. Or even bad ones. Jim (the Answer Guy himself) attributes this to all the good questions having already seen answers in past columns. This can't be completely the case - and on rare occasions the answers do change and why they had to is a juciy discussion. But there's certainly some grain of truth to it.
We like it when more people ask the answer gang their linuxy questions.
Ah, but that's not the topic I've planned to yak about for this month. Maybe in a later column, when The Answer Guy brings back his Retrospectives, I'll do a nice breakdown on how people find helpful friends these days. But I've been having a lot of fun (and even some clients) doing web glitz, so I'm probably going to talk about that next month. Send in your own tidbits of good web techniques, we'll make a pool of them.
I had spring cleaning last month, which means that this month there is room on my desk - and in my office - for some nifty things. Right now my lab's about to bloom with new power and color, as I bring machines from my internet lounge into gear. I haven't decided if I'll run them with full distros this time, a liveCD again as I usually do (Knoppix being the front runner), or as terminals served off one higher quality machine, in the same spirit that the K-12 LTSP people do. One way or another it's bound to be a fun time at Baycon again this year, as my starship gets a Piece O' Da Action. I should invite our Editor In Dark Glasses along, and see if the ladies who fly the black helicopters are inclined to TAG along...
My teddybear now has a permanent place of honor on my FVWM desktop. If you've been paying attention you've got a copy of him in your /usr/share/xteddy directory too, from our February cover art and perhaps he brightens your day. Thomas gave me a rather sweet birthday present that I hadn't gotten around to showing you folks - note, this is very specific to FVWM, and you have to name your bear correctly, too.
First, you symlink xteddy to the name bear so the window title will be seperate.
Second, add this fragment to your .fvwm2rc. It's kind of important to advise FVWM that he accepts WM hints:
See attached misc/tag/bouncing-bear.fvwm.txt
Third, I added a little bit to my fvwm's StartFunction which makes sure that bear's on my desktop. You'll probably have the geometry a little different - have fun with it...
AddToFunc StartFunction + I Test (init) Exec exec /usr/bin/fvwm-root /home/heather/.fvwm/stars16a.xpm + I Test (init) Exec exec bear -wm -geometry +1320+820
Now anytime I press Shift-Alt-B he bounces. The only mystery I haven't solved - feel free to send in if you're a fvwm fan who knows the answer - is that if I have clicked him, say to drag him out of the way momentarily - then he won't bounce anymore, until I've minimized him. then his minimized form bounces fine, and so does his restored form. Pretty silly seeing the word with no picture bounce like that. It makes me giggle.
I hope you're enjoying a happy Summer. As for me, it's too bright out there, time to go hide in my starfields for awhile. Stargazing fans, the skies are clear, and there's plenty of software to tell us what to look for. In the realm of spaceward travels, things are... if you'll pardon the expression... looking up. Bye now!
You, too, can join The Answer Gang. Send your submissions to: tag .at. linuxgazette.net - Thanks!
From Matthias Arndt
Answered By: Thomas Adam
Dear Answer gang,
it has been more than 4 years that I am reading (and sometimes publishing in) the Linux Gazette with real pleasure. I always did find most answers to my questions here but this time I'm really stuck.
From time to time I use the Xnest command to connect to remote boxes with graphical login.
This works much as expected except for one thing: I'm used to a german keyboard layout and my local X server is configured to use it. But Xnest does not use it - I always get US keyboard layout inside Xnest. For example I tried:
$ Xnest :1 -broadcast -xkbmap de -geometry 980x680 Cannot open "keymap/de" for reading (EE) Error opening keymap file de, reverting to defaults
for example but I got above error and still only got a US keyboard inside. The rest was working as expected. Another try was something like this:
$ Xnest :1 -broadcast -xkbmap /etc/X11/xkb/keymap/xfree86 -geometry 980x680 Cannot open "keymap/etc/X11/xkb/keymap/xfree86" for reading The XKEYBOARD keymap compiler (xkbcomp) reports: > Error: Cannot open "/var/tmp/etc/X11/xkb/keymap/xfree86.xkm" to write keyboard description > Exiting (EE) Couldn't load XKB keymap, falling back to pre-XKB keymap (EE) Error opening keymap file /etc/X11/xkb/keymap/xfree86, reverting to defaults
The main question is: how do I need to call/configure Xnest that it will use my german keyboard setup inside the Xnest window so that I can use remote applications with my german keyboard?
I'm using SuSE Linux 9.1 with XFree86 Version 4.3.99.902 (4.4.0 RC 2) and the according version of Xnest.
[Thomas] The problem you have, Matthias, is that Xnest does not support the -xkbmap inherently. Yes, although Xnest will emulate a server, at present Xnest is only capable of using its own default keyboard extension map.
You have to remember that Xnest is a complex program. To the Xserver and indeed any other Xclient, it looks and behaves as such (it looks like an Xserver to the underlying real Xserver, and as an Xclient to the windows mapped to it) [1]. The reason why the -xkbmap is ignored is because when Xnest loads, it changes the keyboard layout procedures of the real server to its own defaults [2]. Currently there is no pure workaround, other than you might be able to use Xmodmap from within Xnest to change it (or possibly Xkeycaps).
I realise I've been vague about some points, but this is a really complex issue that I might (if the interest is high enough) turn into an article or TAG entry.
- This has several inherent problems, that I'll skip.
- To many people, this is complex to work around -- but think about. Xnest is both an Xclient and an Xserver (in this sense). The kdb extensions are inherently supplied and then dropped by the real Xserver. It's a transparent process only.
From Suramya Tomar
Answered By: Benjamin Okopnik, Pete Jewell, John Karnes, Mike Orr, Jay R. Ashworth, Kapil Hari Paranjape
Hi Everyone, I have a question for you about file mtime(modify time) on linux. Does the mtime stamp of a file change as soon as a process starts modifying the file or does it change it after the change is done?
[Ben] After the change is done, of course; up until that time, the file has only been read, not written to. What is modified (in e.g., an editor) is a copy of the file, generally held in memory - which is why the "save" function exists. Otherwise, a crash in the middle of editing would destroy your original file.
The reason I am interested in this is that I am writing a perl script which is supposed to monitor a file for changes and as soon as the change is done run another script which processes the changed file. I don't want the second script to run before the file change is complete(Which would happen if the mtime changes as soon as the modification starts).
So how would I check that the file change is done?One way would be to keep checking in a loop if the mtime changed if it did goto sleep and check again after a few seconds, keep repeating this until the mtime stop changing. But in my opinion this is a stupid way of doing this so I am hoping one of you has a better way of doing it.
[Kapil] File locking might be useful. The script sees the change in the mtime, then waits for the lock to go away and starts processing. You would have to tell the modifying program to use file locking though.
[Sluggo] I would agree to use the kernel monitor first. But for alternatives...
Why not have the first process send the second process a signal when it's done? Put the observing process in indefinate sleep, and have the write process send a SIGALRM (Alarm) to kick it. You'd prob'ly want to put the observer's PID in a well-known file so the other process can find it.
Or use file locking. The writer holds a write lock till it's done. The observer sees the mtime change and acquires a read lock. The read lock blocks until the write lock has released.
If you really want to know when the mtime is set, look in the kernel source. or the libc source, and see what fwrite() does. That's one of the advantages of open-source software. Even if you don't know much C, you can still tell whether the word "mtime" appears above or below a write() call.
Or just think about why most programs don't have to worry about this. Unix programs tend to open-write-close quickly, and close the file when they don't need it. (As opposed to Windows text editors, which often hold the file open the whole time.) Unless the program has to hold the file open for a long time (e.g., streaming log entries), your chances of hitting the file in the middle of an update are pretty slim. Then think about, what's the worst that would happen if you did? Your observer would produce garbled output, with part of one version and part of another. Or maybe it would crash. Would this be the end of the world or a minor inconvenience? At least it would tell you how (in)frequently such a collision is occurring.
[Pete] From past experience I seem to remember that the only 'pure perl' way to ensure that a file is not being modified, without relying on file locks, is to check the size/mtime of the file, wait a bit, and then check it again, repeat until the two size/mtimes are the same.
The reason I ran into this was because I was writing a routine to process a file after it had been uploaded to an ftp server. In the end, because we had control over the ftp server, we configured it so that the uploader and my routine both logged into the ftp server using the same username, and restricted the number of times a user could concurrently login to 1. This did the trick quite nicely.
A good resource for perl questions is the Perl Monks website http://www.perlmonks.org - in fact I would go so far as to say that it is the best resource for perl information on the web.
[Ben] [grin] Multiple xterms are useful for this. In one of them, run this program:
See attached mike.show-mtime.pl.txt
where "foo" is the file you're looking at; this will print the mtime of 'foo' once a second. In another xterm, open 'foo' and modify to your heart's content - all the while glancing at the first term. Nice and easy.
[John Karns] How about making a call to 'lsof' to see if the file is open?
I'm not sure if a latency in the kernel flushing disk buffers would be a concern in this kind of scenario. If so, you might want to have either one of the processes make a call to flush the buffers to ensure that there is not a pending update to the file.
In fact I've sometimes wondered about this myself: if there is a pending write to a file via a dirty buffer, is that automatically taken into account if I read the file before the buffer is flushed? I.e., is the pending change transparently mapped to a read of the file by libc or whatever?
[Sluggo] It would be a very severe bug if it didn't read from the buffer, since that's the official version currently. I've sometimes wondered this myself, but I've found the kernel developers pretty trustworthy so I assumed they wouldn't do such a thing.
[Jay] It seems to me that the kernel should update the mtime in the inode (as the inode is transparently cached in RAM) *everytime a write(1) call is made to the file*.
So, at this point, your question expands to "if someone makes a write call which takes a finite amount of realtime to execute (like, writing 1MB from a RAM buffer to a file), at which end of the execution of that write call will the inode get updated?"
IANAKH, but I believe the pertinent code is in kernel/fs/$FILESYS/file.c
http://www.ibiblio.org/navigator-bin/navigator.cgi?fs/ext2/file.c
and specifically the function ext2_file_write() (for ext2).
Short version:
- ext2 updates the inode after it writes the actual data,
- since it's buffered, the order in which the actual bytes hit the disk is indeterminate, and
- it's filesystem specific, since the answer to the question lives in a filesystem specific location in the source.
The specific answer lies in the relative positions of ll_rw_block() and the assignment to inode->i_mtime in the function.
Wow, I didn't expect my question to generate such a big response. Now I know why I like TAG :)
NEways I did a little research after reading all your answers and found the following:
The file modification time changes continuously when the file is being created/modified. (For example when creating the file using cp).
To test this I wrote the following perl script that displays the mtime of my test file every 1 second:
See attached suramya.show-mtime.pl.txt
Then I opened another xterm window and ran the following command: 'cp /var/log/messages test.dat'
suramya@StarKnight:~/Temp$ perl test.pl Time: 1113452801 Time: 1113452801 Time: 1113452801 Time: 1113452801 Time: 1113452801 Time: 1113452801 Time: 1113452801 Time: 1113452890 <-- Changed Time: 1113452891 <-- Changed Time: 1113452891 Time: 1113452893 <-- Changed Time: 1113452894 <-- Changed Time: 1113452895 <-- Changed Time: 1113452896 <-- Changed
As you can see when the copy started the numbers started changing. So now we know that the mtime keeps changing when the file is being modified. And if you think about it, it makes sense: The mtime changes whenever any changes are made to the inode's used by the file so when the file is being created new inodes are being used constantly so the mtime has to change.
Now I will be looking into the other suggestions you guys made and see if I can get this to work. (And no this is not a school project ) I need to export data from an oracle DB to a CSV file and have another script read this CSV file and process it. If the second script reads a half written file 'Bad Things' (TM) will happen.
[Pete] If that's the case, then a low tech solution might suffice. Write your CSV file out from oracle as something like 'temp_output.csv', and then have your oracle process rename the file once it's fully exported. Then your perl script is only looking for the renamed file, instead of trying to guess when the file creation is complete.
[Ben] Oh, nice solution, Pete! You could even follow the (more or less) standard practice of "building" the file in a temp dir, then moving it into the location from which it should be copied. As long as the temp and the final locations are on the same partition, that's just a matter of changing the inode info - which is an atomic op, so there's no chance of retrieving a partial file.
Thanks a lot. This solution works perfectly for my task. Makes my life a lot simpler too :)
From Kapil Hari Paranjape
Answered By: Thomas Adam
This reply is a followup to http://linuxgazette.net/issue114/tag/4.html but is more specific to X11 itself. -- Thomas Adam
But I'm often confused as to what "the other half does". For example, I am now using "fvwm" (thanks to Thomas' suggestions on how to ratpoison-ify it). I know that "fvwm" traps some keys and uses them for its own nefarious purposes.
[Thomas] Key-bindings as set by the user for the window manager are always greedy with respect to the window manager. So for instance, in FVWM, one might have a key-binding such as:
Key X A 3 Function FvwmTitleRxvt
Now, of course, it might be the case that windowskey+X is an actual binding to an application I have running, but it's tough -- the WM has precedence in that binding as I have it defined there.
What happens when it is used with GNOME? Who is gets the first option to look at the keys or other input events? GNOME or fvwm?
[Thomas] Always the window manager. Remember that GNOME is just a framework and a collection of utilities. If you wanted a hierarchy, a depiction such as the following is an accurate representation:
GNOME <--> window manager --> Application
Of course, the integration aspect of GNOME <--> Window Manager how depends on EWMH. I've talked about these in the past, but I might as well summarise them here for clarity. EWMHs are extensions from window states which were first outlined by the ICCCM manual [1]. Unfortunately, the ICCCM is rather old, but it does provide a fantastic framework on which to build a WM, and it is still very relevant today. When KDE and GNOME were developing into the bloatware we see today, one thing they both did were to extend the ICCCM to define their own window states. Of course, compatability became a nightmare in such instances, and so these were cleaned up and standardised by the freedesktop people [2]. They're only windowing hints at the end of the day for things such as 'Working areas', 'Number of Desktops', and such like.
You may ask why the WM has precedence over an application, when it is the job of the WM to manage applications. The answer is simple. Key-bindings are the job of the Xserver. So actually the propogation looks like this:
Xserver -> Window Manager -> Application.
When you get your window manager to bind your keys for you, what's actually happening is that the window manager will map the requests itself, so it keeps a record of WM-specific keybindings. When the WM grabs the Xserver when it maps an application or a key-binding it then checks to see (via the Xserver) whether that keybinding is WM-defined or not. If it is then it will act appropriately, else it will pass it down to the underlying application, or do nothing.
A similar question could be raised regarding how window positioning and decorations are decided/executed. Perhaps the overall GNOME/GTK theme decides and passes on the info to the window manager which actually executes these?
[Thomas] Not quite. GTK itself is window manager agnostic. When you apply a GTK-theme, all that happens is that any currently running GTK apps are redrawn by the Xserver. There is no interaction with the window manager in anyway while this is happening.
Of course, GTK themes don't really allow for the stylation of title bars -- that's the job of the WM, and rightly so. You have to remember thatit's the job of the xserver to map the window which the WM then grabs and decorates as it sees fit. So the decoration could come in any form.
Window positioning is a separate entity in itself. When windows are mapped to the Xserver, the server will naturally map it to 0+0 which is top-left. The window manager already has one window that is top-level, and that is the root-window. This is the ultimate window from which everything else stems from, when windows are created. Consider the following Xlib snippet:
win = XCreateSimpleWindow(dpy, DefaultRootWindow(dpy), xsh.x, xsh.y, xsh.width, xsh.height, bw, bd, bg);
I could easily spend hours talking about this line of Xlib alone, but I'll save you the gory details. Essentially, the point you should realise is that all windows created in this way [3] are always a child of the root-window. Why? Well, it's all about management. Once the Wm knows the top-level window, it knows how to stack windows as well as place hints on them. Of course, the WM is not allowed to change application-set windowing hints when the window is being mapped. Indeed, this is really where 'xprop(1)' comes in useful. This allows one to examine all of the window states as well as set them. There's also 'xwininfo(1)' for a more high-level view, although to be honest, I prefer FvwmIdent for such things.
Of course, with window hierarchies comes the notion of Transient windows. These are (by definition) short-lived windows, such as dialog boxes. They'll often have the the following hint set:
[n6tadam@station ~]$ xprop | grep -i trans WM_TRANSIENT_FOR(WINDOW): window id # 0x2a0002e
The window manager might well treat these differently -- indeed, FVWM does. Due to their short-lived nature, it's often not desireable to have all buttons on the titlebar, so FVWM might well not decorate transient windows in such a manner. Of course, one can change that with:
Style * DecorateTransient
Anyway, window positioning is managed by the window manager. The geometry of a window defines its position on screen, and hence its size. In the form:
widthx height+/- xorigin+/- yorigin
Note that the window geometry will often be with respect the actual window itself, and not the frame that surrounds it. In slight relation to that is a window gravity. There's 'Window Gravity' and 'Bit Gravity', and they specify for the window as a whole (including the borders) and the window contents how to react on window resizing.
Of course, as you have no doubt guessed, it is not quite as simple as -geometry. There is certain other hints that provide additional positioning. Take for instance Mozilla. That doesn't have a '-geometry' option because of they way it was designed. Instead that remembers its position (and hence window size) each time it is closed. The WM can be instructed to ignore or react to such things. As is the case with FVWM there's a hint called 'NoPPosition'. This instructs FVWM to place the window based on what/where it tells the WM to put it. Hence:
Style gecko NoPPosition
would be such an example [4]. There are instances though where a window will use PPosition hints as well as accept geometries. Notably, [X]emacs is such a beast and will set its PPosition to (0,0) each time, so overriding that is paramount for some. Again, geometry specifications take precedence over PPosition hints where they're supported.
A pointer to relevant sources of information would be greatly appreciated.
[Thomas] I hope this helps. I could rabbit on for ages about all of this, but I'd rather answer such things as they come up, as opposed to overloading you with tedious information. Unfortunately, information such as this is sparse, and represents my understanding through working with FVWM, and Xlib in general.
- http://tronche.com/gui/x/icccm
- http://standards.freedesktop.org/wm-spec/wm-spec-1.3.html
- Of course, it doesn't have to be at the low-level such as Xlib. Often, languages have wrapper functions around XCreateSimpleWindow() which will automatically map a window to be a child of the root window.
- http://fvwm.lair.be/viewtopic.php?t=273
Dear Thomas,
Thanks for the detailed write-up. Any chance that this will one day become an article somewhere? (Hint! Hint!).
Great stuff.
This question was raised about a specific window flag. I've split it out from the above commentry to keep readability intact. -- Thomas Adam
[Thomas] Of course, as you have no doubt guessed, it is not quite as simple as -geometry. There is certain other hints that provide additional positioning. Take for instance Mozilla. That doesn't have a '-geometry' option because of they way it was designed. Instead that remembers its position (and hence window size) each time it is closed.
[Ben] Oh, how I wish it did. Not a big thing, but this has been a long-standing problem with Mozilla for me (both the Big Moz and now Firefox): Due to couple of info bars that I use (MailDooHicky and the Moaning Goat Meter),I like for my windows to span from the left edge of the screen to ~100px short of the right edge, and from ~30px down from the top to ~30px short of the bottom. Xterms are, of course, no problem - I've got "XTerm*VT100*geometry: 134x40+0+21" in my ~/.Xresources, and that takes care of it. Mozilla, well... I've got a little Java bookmarklet on the toolbar that makes it jump to the correct position whenever I find it too annoying. But it never remembers the position.
[Thomas] It does work, but it's dependant on how the window manager deals with such things. I have to say that some WMs are better than others in this regard. It has been many years since I used icewm for any serious use, but as far as I can recall, it doesn't allow for arbitrary commands to be run on a window.
[Ben]
Eh, well... for certain values of 'arbitrary'... kinda sorta. :) You can't (so far as I know, at least) run commands on a window once it's up. You can, however, assign initial properties to windows (actually, your discussion of all this stuff is what I needed to remind me of that - thanks!) by defining them in ~/.icewm/winoptions; in this case, what I needed was:
Gecko.Firefox-bin.geometry: 1212x722+0+23
This sets the initial position of the window to what I need, which is perfect.
[Thomas] I hate to err, draw comparisons.
[Ben] No you don't. C'mon, you love to tout the superiority of FVWM! (And why not? If it can do something better than everybody else, go for it. After all, it's not boasting if you can do it.)
[Thomas] In FVWM, doing what you're describing above can be achieved in two ways, the first is to use a function, as in:
DestroyFunc FuncStartMoveBrowser AddToFunc FuncStartMoveBrowser + I Exec exec $0 + I Wait $0 + I Next ($0) ResizeMove w+0 -100px 0 -30p
(I've most likely got the co-ordinates wrong, but that can be left as an exercise to the reader).
So the above will exec the first formal argument to the function ($0), wait for it to appear, and then will move and resize it to the said co-ordinates. You might invoke it thus:
FuncStartMoveBrowser mozilla
One would replace 'mozila' with whatever program was wanted. But there are limitations with that method. The first one is that it will only work when invoked from within a menu, or FvwmConsole, and won't work if one were to type in 'mozilla' from an Xterm. In such cases where this is more desirable, FvwmEvent can be used, as in:
DestroyModuleConfig FvwmEvent-Browser: * *FvwmEvent-Browser: Cmd Function *FvwmEvent-Browser: add_window FuncStartMoveBrowser
Which would set up an event for each window that was created, calling the function specified. The function as we have it defined needs modifying for use with FvwmEvent, as the window would have already been created, hence:
DestroyFunc FuncStartMoveBrowser AddToFunc FuncStartMoveBrowser + I All (CurrentDesk, AcceptsFocus, !Transient) ThisWindow ("gecko") ResizeMove w+0 -100px 0 -30p
I've used 'gecko' as that is the window class common to both Mozilla and Firefox.
You're probably wondering how this helps you, Ben. It doesn't, but there is an application which can move and resize windows which you could make use of, coupled with xwininfo(1). It's called 'xwit' and is just a wrapper program around some of the Xlib functions, so for example:
xwit -move x y -resize x y -names 'mozilla'
If you wanted to get specific, you could use xwininfo to fine tune things, matching by window ID, etc. Maybe a little crude, but it might help you.
[Ben] [laugh] Well... it's got this little problem built in...
ben@Fenrir:~$ xwininfo|grep 'Window id' xwininfo: Window id: 0xc00031 "Google Advanced Search - Mozilla Firefox"
Since Firefox changes its window name to whatever the site happens to be, I have to click the Firefox window in order to find out its window ID (which could then be used to do 'xwit' twiddling.) This is, shall we say, suboptimal for the task. I'd imagine there are other ways to hunt it down - 'xwininfo -all -root|grep Mozilla' comes to mind - but that gets a bit shaky. Anyway, you've avalanched some synapses for me, the appropriate brain cells fired, and All Is Now Well. Thanks!
[Thomas] No worries. You can probably get a fairly accurate result in making use of '-root' to xwininfo, so something like:
[n6tadam@station ~]$ xwininfo -root -all -tree | grep -m1 'Mozilla-bin' 0x282c250 "Gecko": ("Gecko" "Mozilla-bin") 200x200+0+0 +0+0
At least with it displayed in a tree form (and stopping at the first match), you can be fairly well assurred that you'll be matching the parent window.
From Jpydeep Bakshi
Answered By: Chris Gianakopoulos, Benjamin Okopnik, Adam Engel, Thomas Adam
Hi all,
I am totally shifted to icewm and I am a newbie on this icewm. that's why I am asking some questions, may be very basic to you all but I don't have much knowledge about it.
1) is it possible to get a customised menu where I'll have some very frequently accessed entries like sylpheed-claws, mplayer etc and nothing else ?
2) how to create shortcuts on desktop ?
[Thomas] Use a program such as rox-filer [1] or 'idesk' (search LG.net for that one, there was an article about it not so long ago). You're also suffering from a fundamental lack of understanding about what a desktop environment is, and what a window manager is. I'm not going to cover it here again - see any of the recent LG releases within the last six months. Essentially the term "desktop" isn't. It's just the root-window.
I'll definitely go through those article. what window manager do you use?
Now a million-dollar question. is it practically possible to run K-desktop environment on xfce or icewm window manager ? if possible then how ? I am too much interested to do such an experiment.
[Thomas] You clearly don't pay enough attention to reading the LG, if at all. :) [2,3]. I suppose you ought to read the recent TAG entries as well [4,5,6].
Only where those window managers are EWMH compliant [3], for which icewm seems to be. This allows things like the kde kicker and gnome's taskbar to be handled correctly from the window manager that will run 'inside' of the KDE or GNOME environment. Effectively this process is using Session Management [2], although in reading that, you would need to replace the current running window manager in GNOME with icewm. You can't use "icewm --replace" as that's specific to FVWM, hence you should use:
killall metacity && sleep 1 && icewm &
Then you'd have to save your session before you logged out (via gnome-session-properties). I have to say that I absolutely hate session managers. I can't stand them. They're terrible at what they do and what they do, is second rate.
If you want to use KDE instead, the process can get a bit trickier - I have heard rumours of the use of candles and goats, but....
KDE is started via the 'startkde' script. If you edit that script what you might see is a line such as:
ksmserver
which starts the window manager (kwin by default). To start fvwm you should add the option "-w icewm" to the ksmserver line, and save the file. On typing 'startkde' this should then launch icewm as the window manager of choice.
Of course, all of this is theory - I don't use icewm so I am just applying what I already know.
[Ben] Thomas already mentioned that you're suffering from a bit of confusion in this regard. You don't "create shortcuts on desktop"; you run an application that allows you to create clickable icons linked to applications. My favorite is "coolicon", which is available as a standard Debian package; it does not come with particularly exciting icons - but you can use any XPM image as an icon, and it's very flexible, powerful, and lightweight.
You can also create clickable links on the IceWM toolbar - here's my ~/.icewm/toolbar file as an example:
prog "BackFlip" "xv.xpm" bkgr prog "Lock screen" "lock_16x16.xpm" xlock -random prog "CD Player" "dvd_unmount_16x16.xpm" grip --small prog "Mix" "music_32ndnote_16x16.xpm" /usr/bin/tkmixer prog "Firefox" "mozilla_16x16.xpm" /usr/bin/firefox prog "JPilot" "pda_black_16x16.xpm" /usr/bin/jpilot # prog "Liferea" "rebuild_16x16.xpm" /usr/local/bin/liferea prog "Snap" "camera_16x16.xpm" /usr/local/bin/snap prog "Cell-up" "randr_16x16.xpm" /usr/local/bin/cell-up
The first string after "prog" is the 'hover label' for the icon, the second one is the 16x16 XPM image to be used, and the third one is the program to execute. Simple and easy.
Furthermore, IceWM allows you to associate programs with other toolbar entities (the mail notification icon, the CPU activity icon, the clock, etc.) See the "preferences" file - same locations as the "menu" file - and search for the word 'Command' (the variables will be MailCommand, ClockCommand, etc.)
3) how to add wallpaper ?
[Ben] You can use "icewmbg", or just use the standard X commands (i.e., "xsetbg").
4) can I add application-button, applet to panel which I could do in KDE ?
[Ben] I think you're asking about toolbar buttons - which I've answered above.
[Chris] I'm an icewm boy. I can answer two of your questions. In your home directory, once you save your preferences with the program called 'icepref', you will have a directory called .icewm. There will be a file called preferences.
For a background image (wallpaper), set the following line:
DesktopBackgroundImage="myfile.jpg"
In this case, a jpeg file will represent your wallpaper.
I have attached another file in that directory called programs. It represents your menu items. The file that I have included is the one that I use. Modify this as you like. In it you will see menu entries, and within each menu entry, you will see prog entries. The prog entries are the selections within each menu.
Actually, I have attached both (preferences and programs) files. If you don't have icepref, just create the directory .icewm in your home directory, and copy the attached files into that new directory.
See attached icewm-preferences.txt
See attached icewm-programs.txt
[Adam] If you're using a Desktop Environment like KDE or GNOME, why do you need a win manager at all, except to literally "manage windows;" that is, what's the difference between Metacity or Icewm or Sawfish if you're already using GNOME with all it's icons, menus, etc.
[Thomas] Because KDEs and GNOMEs framework are such that you can use different window managers within them as long as they're EWMH-compliant. It just so happens that GNOME uses metacity now as its window manager or choice. Before that, it was sawfish.
[Adam] As "stand-alone" win managers, sawfish and metacity don't seem to do much (on my system) -- as compared to window maker or enlightentment or fvwm etc -- yet sawfish and metacity are the "window managers" of GNOME, which doesn't, as far as I know, have a win manager of its own.
[Thomas] That's right, it doesn't. It's allowed for the choice to be down to the user. Of course, most don't bother changing it, because the options that GNOME gives them aren't dependant on the window manager being used, but rather how GTK will react to those events; in the same way that the options GNOME allows for affect the gpanel, etc.
[Adam] I don't understand the relationship of a window manager, such as sawfish, to a full desktop environment such as GNOME. If I want to go with a window manager, I use window maker or enlightenment and customize it, otherwise, I use KDE or GNOME for the "desktop experience." Can anybody explain what the relationship between a window manager and a Desktop Environment like GNOME?
[Thomas] See above -- it's only one half of the equation.
Contents: |
Submitters, send your News Bytes items in
PLAIN TEXT
format. Other formats may be rejected without reading. You have been
warned! A one- or two-paragraph summary plus URL gets you a better
announcement than an entire press release. Submit items to
bytes@lists.linuxgazette.net
Following the European Council of Ministers' decision to discard Parliament's amendments, the legislative process continues. The FFII has reported the publication of the report by Michel Rocard, European Parliament rapporteur, on software patents. The findings and recommendations in the report have been welcomed by FFII president Hartmut Pilch. FFII has also published a recording and some transcripts from the JURI meeting at which the rapporteur's findings were presented.
Although, currently, campaigning for the European Constitution referenda is dominating European politics at the moment, the importance of contacting your MEPs on this matter should not be underestimated. Only by paying attention to their actions, and calling them to account for them (whatever your personal views), can citizens begin to reduce the democratic deficit manifest in EU institutions.
gpl-violations.org has been granted a preliminary injunction against Fortinet UK Ltd., a company that produces and distributes firewalls. Granted by the Munich district court, the injunction follows claims by gpl-violations.org that Fortinet have included various GPL software, including the Linux kernel, into their firewall offerings. Harald Welte, the Linux kernel developer involved in this case, also claims that Fortinet attempted to conceal their appropriate of the relevant code by using cryptographic techniques. Fortinet have admitted that GPL code was included in their product, but have so far failed to satisfactorily resolve the issue.
Using Python on the Nokia S60 mobile phone.
Userspace filesystem encryption with EncFS.
O'Reilly article on Sound editing with Audacity, and meanwhile Linux Journal has looked at Csound.
Comparison of Microsoft Visual Studio and KDevelop.
Ongoing history of open-source software by Peter H. Salus.
Are free-software developers the glimmer of hope for software quality?
Creating a custom Linux LiveCD With PCLinuxOS.
Linux Journal has published A Reading List for Linux in the Classroom, covering topics like OpenLDAP, Samba, and more.
IBM developerWorks has an interesting article that discusses running GNU/Linux or NetBSD on Apple's new Mac mini.
Groklaw's Pamela Jones argues that the SCO case has been good for Linux
Slashdot discussion of Linux laptop compatibility, while OSnews has Linux on A Laptop: A Tinkerer's Journal.
NewsForge has published a brief review of the UseMod Wiki.
The challenges of analysing GNU/Linux use.
The maturation of 64bit free OSs.
Has acquisition by Novell hurt SuSE on its German home turf.
Volvo are now doing crash simulations on GNU/Linux, in partnership with IBM.
Lawrence Lessig tells Flash developers how how he believes their work and technology is perceived in the open-source community.
Over the years we've seen a number of heated arguments among the members of the Linux kernel project. Favourites among these have included the debates over preemption strategies and discussions of how to manage memory most effectively. A repeated focus for acrimonious discussion has been Linus's choice of source-management tool: BitKeeper. The selection of a proprietary piece of software for this fundamental part of the development infrastructure has rankled many of the more idealistic open-source/free-software purists in the development community.
This issue came to major prominence in the past month, as Andrew Tridgell publicly revealed that he had reverse engineered the BitKeeper protocol to allow developers to obtain project meta-data from the repository. On seeing this, the lead-developer of BitKeeper, Larry McVoy, responded by revoking the free BitKeeper licences that have been used by kernel developers since the tool was adopted by the project.
This sequence of events drew the ire of Linus Torvalds, who accused Tridgell of acting irresponsibly and jeopardising an effective and working system without offering any alternative. Others in the free software community, such as Bruce Perens, see these criticisms as unjustified, and point out that Tridgell was essentially engaged in the same type of activity that allowed him to develop Samba.
Nonetheless, in spite of these travails, Linux kernel development has not been stopped in its tracks. An alternative tool, git, to manage the kernel source (advice for beginners). Following the successful import of kernel source into git, the 2.6.12rc3 release is the first to be built up completely using git.
An interesting aside to consider is the response of the Subversion project to discussion among users that Subversion might be a suitable BitKeeeper replacement. Highlighting the difficulties in achieving a compromise between Linux development practice and the current Subversion feature-set, attention was instead briefly focussed on three new version control systems that have emerged in the past year or two Monotone GNU Arch and SVK. All three of these support the use of distributed repositories, and have recently been gaining popularity.
The newest iteration of the stable 2.6.x series of Linux Kernels is now available. Linux 2.6.11.7, released on April 7th, includes a collection of fixes. In line with the new kernel numbering scheme, post 2.6.11, this release should only include minor fixes to the original 2.6.11 release.
Debian Weekly News has reported the availability of a HURD Live CD. This is a great opportunity to try out the long (long!) awaited HURD kernel.
Archie is a complete live Arch Linux system (v0.7) that can be run from a CD/USB. OSDir has a screen-shot tour of the distro.
Debian stable (Woody) has been updated with the release of Debian GNU/Linux 3.0r5. The complete list of accepted/rejected packages in this release can be seen at http://people.debian.org/~joey/3.0r5/
Branden Robinson has been elected as the new leader of the Debian Project. He has given an interview where he outlines some of his plans.
From Debian Weekly News, Hanna Wallach has written an essay about making Debian a friendlier place for both men and women. Apparently, a significant number of men participate in the Debian Women project because it offers of a much more positive, welcoming, and friendly atmosphere than other Debian fora.
LinuxTimes.net has a review of Kanotix, a Debian Sid based live CD.
OSnews has a review of Linspire. Linspire is a GNU/Linux distribution aimed at providing an easy-to-use environment for users migrating from Windows.
Mad Penguin has taken a look at SuSE 9.3 Professional.
Ubuntu has released a new edition of its popular, Debian-based, GNU/Linux distribution. Ubuntu 5.04, (The Hoary Hedgehog Release) is in the wild and ready for download. In parallel with this, The Kubuntu project has released Kubuntu 5.04 (Ubuntu combined with the latest KDE goodness).
Linux Journal has recently taken a look at this rapidly growing distro.
The Apache Project has announced the release of the newest version of its omnipresent web-server software. Apache HTTP Server 2.0.54, now available for download, is principally a bug fix release.
Those more familiar with the interface used by Blender, the popular open-source 3D modelling package may be interested in instinctive Blender. This fork has been profiled at NewsForge.
Not directly Linux related, but surely of interest to most Unix-like system admins (or should that be admins of Unix-like systems!), O'Reilly has recently released a new title focussing on security issues and techniques on BSD systems: Mastering FreeBSD and OpenBSD Security.
Mick is LG's News Bytes Editor.
Originally hailing from Ireland, Michael is currently living in Baden,
Switzerland. There he works with ABB Corporate Research as a
Marie-Curie fellow, developing software for the simulation and design
of electrical power-systems equipment.
Before this, Michael worked as a lecturer in the Department of
Mechanical Engineering, University College Dublin; the same
institution that awarded him his PhD. The topic of this PhD research
was the use of Lamb waves in nondestructive testing. GNU/Linux has
been very useful in his past work, and Michael has a strong interest
in applying free software solutions to other problems in engineering.
A first step towards qualitative understanding and interpretation of scientific data is visualization of the data. Also, in order to reach a quantitative understanding, the data needs to be analyzed, e.g. by fitting a physical model to the data. The raw data may also require some initial processing in order to become useful, e.g. filtering, scaling, calibration etc.
Several open source programs for data analysis and visualization exist: gnuplot, grace, octave, R, and scigraphica. Each of these has its own pros and cons. However, it seems like you always end up using more than one program to cover all the different needs mentioned above, at least if you don't have the programming abilities to write your own custom programs using e.g., Fortran or C.
Recently, I came across Python and found it to be a very powerful tool. In this article, I would like to share my experience and illustrate that even with basic (or less) programming skills it is still possible to create some very useful applications for data analysis and visualization using this language. The article is centered around a few illustrative examples and covers the visualization part — data analysis will be covered in a future article.
Python was originally created by Guido van Rossum and is an interpreted programming language (like e.g. Perl) with a clear and easy-to-read syntax. You can write stand-alone applications with Python, but one of it's strengths is its ability to act as glue between different kinds of programs.
The standard introduction to any programming language is the
Hello world! program. In Python this is generated by first
opening the Python interpreter by typing python
on the
command line. Your screen should look something like this:
Python 2.3.4 (#1, Jan 21 2005, 11:24:24) [GCC 3.3.3 20040412 (Gentoo Linux 3.3.3-r6, ssp-3.3.2-2, pie-8.7.6)] on linux2 Type "help", "copyright", "credits" or "license" for more information. >>>Then the following code is typed:
print "Hello world!"
Python code can also be stored in a file e.g. named
script.py
. By convention, files containing python code
have a *.py
extension. The script can be executed by
typing python script.py
on the command line. The
program output will then be written to stdout and appear on the
screen. If the following line is added to the top of the file:
#! /usr/bin/python
(assuming that the python executable or a symlink to it exists)
and giving the file executable mode with chmod u+x
script.py
the script can be executed by typing
./script.py
on the command line.
Python comes with many modules, either built-in or available for separate download and installation. In this article we will use SciPy, which is a very powerful library of modules for data visualization, manipulation and analysis. It adds functionality to Python making it comparable to e.g. octave and matlab.
The first example illustrates plotting a 2-D dataset. The data to be plotted is included in the file tgdata.dat and represents weight loss (in wt. %) as a function of time. The plotting routine is in the file tgdata.py and the python code is listed below. Line numbers have been added for readability.
1 from scipy import * 2 3 data=io.array_import.read_array('tgdata.dat') 4 plotfile='tgdata.png' 5 6 gplt.plot(data[:,0],data[:,1],'title "Weight vs. time" with points') 7 gplt.xtitle('Time [h]') 8 gplt.ytitle('Hydrogen release [wt. %]') 9 gplt.grid("off") 10 gplt.output(plotfile,'png medium transparent picsize 600 400')
To run the code, download the tgdata.py.txt file, rename it
to tgdata.py
, and run it with python
tgdata.py
. Besides Python, you also need SciPy and gnuplot
installed. Gnuplot version 4.0 was used throughout this article.
The output of the program is a plot to screen as shown below.
The plot is also saved to disk as tgdata.png
per line
4 above.
In line 1, everything from the SciPy module is imported. In order
to make use of the various functions of a module, the module needs
to be imported by adding an import module-name
line to
the the python script. In this case it might have been sufficient
to import only the gplt
package and the
io.array_import
package. In line 3 the
io.array_import
package is used to import the data
file tgdata.dat
into the variable called
data
as an array with the independent variable stored
in column 0 (note that array indices start with 0 as in C unlike
Fortran/Octave/Matlab where it starts at 1) and the dependent
variable in column 1. In line 4 a variable containing the file name
(a string) to which the plot should be stored. In line 6-10 the
gplt
package is used as an interface to drive gnuplot.
Line 6 tells gnuplot to use column 0 as x-values and column 1 as
y-values. The notation data[:,0]
means: use/print all
rows in column 0. On the other hand data[0,:]
refers
to all columns in the first row.
The gnuplot png option picsize
can be a little
tricky. The example shown above works when Gnuplot is built with
libpng + zlib
. If you have Gnuplot built with
libgd
the required syntax becomes size
and the specified width and height should be comma separated.
In order to plot a file with a different file name, we have to open the python source in a text editor and manually change the name of the file to be imported. We also need to change the name of the file copy if we do not want to overwrite the previous plot. This is a little tedious. We can easily add this functionality to our python script by allowing filenames to be passed as command line arguments. The modified script is called tgdata1.py and is shown below.
1 import sys, glob 2 from scipy import * 3 4 plotfile = 'plot.png' 5 6 if len(sys.argv) > 2: 7 plotfile = sys.argv[2] 8 if len(sys.argv) > 1: 9 datafile = sys.argv[1] 10 else: 11 print "No data file name given. Please enter" 12 datafile = raw_input("-> ") 13 if len(sys.argv) <= 2: 14 print "No output file specified using default (plot.png)" 15 if len(glob.glob(datafile))==0: 16 print "Data file %s not found. Exiting" % datafile 17 sys.exit() 18 19 data=io.array_import.read_array(datafile) 20 21 gplt.plot(data[:,0],data[:,1],'title "Weight vs. time" with points') 22 gplt.xtitle('Time [h]') 23 gplt.ytitle('Hydrogen release [wt. %]') 24 gplt.grid("off") 25 gplt.output(plotfile,'png medium transparent picsize 600 400')
In the first line we have imported two new modules —
sys
and glob
— in order to add the
desired flexibility. In Python, sys.argv
contains the
command line arguments when execution starts.
sys.argv[0]
contains the filename of the python script
executed, sys.argv[1]
contains the first command line
argument, sys.argv[2]
contains the second command line
argument and so on. The glob.glob()
function behaves
as ls
in *nix environments in that it supplies
filename wildcarding. If no matches are found it returns the empty
list (and thus has a len() of zero), otherwise it contains a list
of matching filenames. The script can be executed with any desired
number of command line arguments. If executed with two arguments
e.g. python tgdata1.py tgdata.dat tgdata1.png
the
first argument is the name of the file containing the data to be
plotted, and the second argument is the desired name of the file
copy of the plot.
The script works as follows. A default file name for the hard
copy of the plot is stored in the variable plotfile
(line 4). Then some conditions about the number of given command
line arguments are checked. First, if two or more command line
arguments are given plotfile
is overwritten with
argument no. 2 (line 6-7.) Any arguments after the second are
silently ignored. For 1 or more arguments given argument 1 is used
as the data file name (line 8-9). If no command line arguments are
passed, the user is prompted to input the name of the data file
(line 10-12). In case of an invalid file name being used for the
data file the script prints an error message and exits.
So far we have shown that the gplt
package is easy
to interface with gnuplot and very effective. However, for
scientific use it is often desirable to represent uncertainties for
each data point. Although this is possible in gnuplot the
gplt
interface lacks this functionality. Instead we
use the popen
package included in the os
module. With popen
it is possible connect to the stdin
(or stdout) of a program through a pipe.
The code below (also available in xrddata.py.txt, the data file
is available as xrddata.dat) more or less shows
how example 1 is reproduced using popen
instead of the
gplt
package. The major difference is the fact that
with popen
it is not necessary to import the data to
be plotted into Python - instead it is read directly by
gnuplot.
1 import os 2 3 DATAFILE='xrddata.dat' 4 PLOTFILE='xrddata.png' 5 LOWER=35 6 UPPER=36.5 7 8 f=os.popen('gnuplot' ,'w') 9 print >>f, "set xrange [%f:%f]" % (LOWER,UPPER) 10 print >>f, "set xlabel 'Diffraction angle'; set ylabel 'Counts [a.u.]'" 11 print >>f, "plot '%s' using 1:2:(sqrt($2)) with errorbars title 'XRPD data' lw 3" % DATAFILE 12 print >>f, "set terminal png large transparent size 600,400; set out '%s'" % PLOTFILE 13 print >>f, "pause 2; replot" 14 f.flush()
The code of example 2 produces the output shown below. The error
bar plot is created with plot 'filename' using 1:2:(sqrt($2))
with errorbars
because in xrddata.dat the standard
deviations are equal to the square root of the y-values. This is a
special case and usually errors are given explicitly as a third
data column in the data file. Thus, an error bar plot is created
with plot 'filename' using 1:2:3 with errorbars
.
Now we look at how 3-D data can be represented by using a combination of Python/gnuplot. In order for gnuplot to represent 3-D data it requires that the data is either given by a mathematical expression or stored in a data file. The data file should have either a matrix-format where z-values are given as a matrix with x and y equal to the row and column number, respectively, corresponding to each z-value or a 3 column format where each row represents a data triple with x, y, and z given by the 1., 2., and 3. column respectively. See the gnuplot manual for further details.
The data to be represented in a 3-D fashion in this example is actually a collection of 2-D data files (like the one shown in example 2). Each data file corresponds to an experiment at a different time (with 150 s intervals between experiments) so we have two independent variables and one dependent variable: x(file number/time), y (diffraction angle),and z(counts) distributed across several files. This makes the 3-D data not suitable for plotting — yet.
The script 3ddata_1.py shown below finds
all files with a given extension (*.x_y in this case) in the
current working directory and creates a list containing their file
names (line 5, FILELIST
). In line 6 the number of data
rows in each file is determined (SIZEX
). This
information, including the number of data files, is then used to
construct an array (DATAMATRIX
) with a size of
SIZEX
by len(FILELIST)
. In lines 11-12 we
cycle through the data files copying the second column in datafile
number y is copied to column number y in DATAMATRIX
.
The array now holds all z-values. This array is only temporary,
suitable for data processing before the actual data file for the
3-D plotting is written.
In line 14-22 the data file is written in the (x,y,z) format
with x corresponding to time (found by multiplying the file number
with the time step), y corresponding to diffraction angle as given
by TWOTHETA
, z corresponding to counts. In this case
we only want to plot the data with diffraction angles between 35-60
(corresponding to data rows 1126-1968). Therefore, only this range
is written to file in order to speed up both the process of writing
to file and the plotting. In line 24-29 gnuplot is fed input using
the popen
package.
1 import os, glob 2 from scipy import * 3 4 EXT='*.x_y' 5 FILELIST=glob.glob(EXT) 6 SIZEX = len(io.array_import.read_array(FILELIST[0])) 7 DATAMATRIX = zeros((SIZEX,len(FILELIST)), Float) 8 TWOTHETA=io.array_import.read_array(FILELIST[0])[:,0] 9 TIMESTEP=150 10 11 for y in range(len(FILELIST)): 12 DATAMATRIX[:,y]=sqrt(io.array_import.read_array(FILELIST[y])[:,1]) 13 14 file = open("3ddata.dat", "w") 15 16 for y in range(len(FILELIST)): 17 for x in range(1126,1968): 18 file.write(repr(TIMESTEP*y)+" "\ 19 +repr(TWOTHETA[x])+" "+repr(DATAMATRIX[x,y])) 20 file.write("\n") 21 file.write("\n") 22 file.close() 23 24 f=os.popen('gnuplot' ,'w') 25 print >>f, "set ticslevel 0.0 ;set xlabel 'Time [s]'; set ylabel 'Diffraction angle'" 26 print >>f, "set pm3d; unset surface; set view 60,75; splot '3ddata.dat' notitle" 27 print >>f, "set terminal png large transparent size 600,400; set out '3ddata_1.png'" 28 print >>f, "replot" 29 f.flush()
If you wanted to write a 3-D data file in the matrix-format, lines 14 through 22 can be replaced with the following code.
file = open("3ddata_matrix.dat", "w") for x in range(SIZEX): for y in range(len(FILELIST)): file.write(repr(DATAMATRIX[x,y])+" ") file.write("\n") file.close()
The 3-D plot produced by the above script is shown below.
The plot above shows that it can be difficult to produce a 3-D plot of non-monotonic data that shows all of the details of the data — some of the smaller peaks are hidden behind larger peaks. It is also difficult to see changes in peak positions as a function of time. In order to bring out these details it is sometimes better to create a 2-D contour plot by projecting the z-values down into the x,y plane. This is achieved by replacing lines 24-29 of 3ddata_1.py with the code below (3ddata_2.py).
f=os.popen('gnuplot' ,'w') print >>f, "set pm3d map; set palette rgbformulae 30,31,32; set xrange[0:4500]" print >>f, "set xlabel 'Time [s]'; set ylabel 'Diffraction angle'" print >>f, "splot '3ddata.dat' notitle" print >>f, "set terminal png large transparent size 600,500; set out '3ddata.png'" print >>f, "replot" f.flush()
The contour plot is shown below.
The 3-D example plots were made with 39 data files, each containing 4096
data rows. The data files are available at this offsite
link, and can be unpacked with tar xvfz 3ddata.tar.gz
.
In this article a few examples have been given in order to
illustrate that Python is indeed a powerful tool for visualization
of scientific data by combining the plotting power of gnuplot with
the power of a real programming language. It should be noted that
all the examples given here could probably have been solved with a
combination of e.g. bash
, gawk
and
gnuplot. It appears to me that Python is much simpler and the
resulting scripts are more transparent and easy to read and
maintain. If heavy data processing is required the
bash/gawk/gnuplot might also need the added functionality of e.g.
octave. With Python this functionality is in SciPy.
Manuals, Tutorials, Books etc:
See also previous articles about Python published in LG.
Gnuplot version 4.0 has been used in the examples throughout this article. Python also works with other plotting engines/libraries:
Anders has been using Linux for about 6 years. He started out with RH
6.2, moved on to RH 7.0, 7.1, 8.0, Knoppix, has been experimenting a little
with Mandrake, Slackware, and FreeBSD, and is now running Gentoo on his
workstation (no dual boot :-) at work and Debian Sarge on his laptop at
home. Anders has (a little) programming experience in C, Pascal, Bash,
HTML, LaTeX, Python, and Matlab/Octave.
Anders has a Masters degree in Chemical Engineering and is currently
employed as a Ph.D. student at the Materials Research Department, Risö
National Laborary in Denmark. Anders is also the webmaster of Hydrogen storage at Risö.
-- Software Development West 2005, Santa Clara Convention Center
-- Open Source Business Conference (OSBC), Westin St. Francis, San Francisco
-- MySQL User Conference, Santa Clara Convention Center
Three significant conferences in March and April provided evidence of a paradigm shift in our industry. Two were for geeks and one was also for IT managers and Gucci-shoed VCs.
The paradigm shift is in group development methodologies - and it's getting support partly from the increasing acceptance of Open Source Software(OSSw). Because OSSw calls for the collaboration of many individual contributors in far-flung locations, Test Driven Development (TDD) is a rising star in the developer world.
The gurus of software design and technique are now extolling TDD, and are finding that it dovetails nicely with other schools of developer best practice. Many gurus, some grudgingly, now extol TDD because the disciplines they have advocated over the years 'just fall out' of the practice of coding test cases first or simultaneously with each module. Tools like JUnit - freely available and open-sourced - reinforce this shift.
We all know we should do our Design work up-front, and that we should code in small modules to encourage reuse, and that Agile and XP programming methods advocate frequent, small steps, and we should regularly refactor code and test performance during development, and... and.... It is interesting that TDD enforces all of these and other best practices without having to attend a lot of classes and reading at least half a dozen books. TDD Just Works™.
First, there should always be a test-case for each bit of code. Second, writing test cases encourages up-front design. Third, you always have working code at the end of a unit. And fourth, consistent with OSSw strategies, major bugs are uncovered early and dealt with in the development phase. Just like in the case of XP, you can have stylistic variations with TDD - but there is a lot more agreement than disagreement.
The new wrinkle with OSSw is that new applications - and new companies - drive value up the stack. A company like Google doesn't spend all of its time just tweaking its web servers; just take a look at Google Maps with its satellite images. It relies on standard hardware and software to be the base for totally new applications. And that standard software is increasingly become dependent on Open Source.
In fact, it's not just about the software itself: it's the utility of that software to a user or company. Google and Yahoo and eBay provide services to users, and the value of those services drives users to their web sites. But it's not the underlying hardware or the OS that necessarily enhance these services; instead, it's how developers leverage the underlying platforms in new and creative ways.
TDD and OSSw have an overlap, a sweet spot where developers become enabled by tools and methodologies that free them up to do the next thing - which will, of course, be totally awesome and amazing, or so goes the promise of this Brave New World. In either case, it's nice that Linux and its OSSw cousins will be part of that.
Conspiracy theorists will speculate about coincidence of the Santa Clara Convention Center hotel, originally a DoubleTree, becoming a Westin. Does that mean that Westin is the chain of choice for techno-geek? Or an open source Mecca? I think not.
At OSBC, the stars were visionaries, suits, and venture capitalists. Small companies were looking for financing, large companies were testing the Open Source waters, and the model of free software and paid support was being refined and extended into an ecosphere of interrelated companies and development communities.
At the MySQL User Conference [I may use MUC as an acronym occasional], however, the emphasis was different: the stars here were Open Source developers, many now employees of a confident, growing MySQL AB, now 10 years old. Since these folks came from over 40 countries, it was a very festive time.
This year, the MySQL User Conference was managed by O'Reilly Media. This kept things interesting and edgy - and attendees were also encouraged to come to O'Reilly's Web 2.0 conference in SF during the fall.
Technical sessions were only 50 minutes long with a 30 min or longer breaks after every two sessions, and even the Monday tutorials were only 3 hours long. Sessions moved quickly, often with little time for Q&A. By contrast, sessions at SD West were almost double at 90 minutes, and some security workshops spanned two sessions in the same room. I preferred the longer ones, since that allowed attendees to move if the material or presentation wasn't what was expected.
The food at MUC was hotel banquet style, and O'Reilly put a book into each of the conference tote bags [for early registrants, at least.] This contrasts with no books and sandwich boxes at OSBC and SD West. The difference may be that O'Reilly and MySQL AB treated the participants as customers, or even potential authors, and cultivated them more.
Another difference was the approach to internet access. At SD West, there was a limited number of internet-connected machines for emailing - but at OSBC and MUC there were none. The assumption there seemed to be that almost everyone has a personal laptop or pocket PC, and the conference organizers only needed to provide wireless access. We'll probably see more of this as a way to cut conference costs, so be prepared to travel to conferences with a 'device' of your own.
Each of the conferences had their stalwarts who come year after year [that was less so at OSBC, since this was only the second year]. However, informal conversations showed a very high level of satisfaction with the MySQL User Conference. This may be partly due to the tighter subject focus and the clear technical levels of the sessions. It may also have been due to the friendly user community that has emerged around MySQL.
Read on to find out more about the individual conferences and their highlights.
Software Development West 2005, Santa Clara Convention Center
Open Source Business Conference (OSBC), Westin St. Francis, San Francisco MySQL User Conference, Santa Clara Convention Center
Howard Dyckoff is a long term IT professional with primary experience at
Fortune 100 and 200 firms. Before his IT career, he worked for Aviation
Week and Space Technology magazine and before that used to edit SkyCom, a
newsletter for astronomers and rocketeers. He hails from the Republic of
Brooklyn [and Polytechnic Institute] and now, after several trips to
Himalayan mountain tops, resides in the SF Bay Area with a large book
collection and several pet rocks.
By Edgar Howell
A friend recently sent me a CD with a version of Knoppix designed to enable surfing the Internet without risk. For its intended purpose alone worth looking at, to me the real mind-blower is its use to recover from disaster.
As chance would have it, I had barely started to play around with it a bit when our nephew called: Blue Screen of Death. No back-up. Cool. Yeah, OK, come on over tomorrow afternoon and I'll see what I can do. Windows?! Well...
This thing was put together by people who really know what they are doing. Their use of symbolic links was sheer genius. Well, OK, if you insist, pretty straight-forward — that's what they're there for.
Knoppix is a self-contained mini-version of Linux on CD-ROM. I had heard of it, of course, but never had the time to investigate it. Big mistake. It is well worth being familiar with.
This particular version is intended basically to turn your PC into something like a diskless workstation. You boot from the CD-ROM and it sets up an environment analogous to a chroot-jail without access to any hard drive. In this environment you can surf with Firefox. Even save settings — to diskette or USB. And when you are all done, whatever you haven't yourself explicitly saved somewhere is history.
No virus. No trojan. No spyware. No cookies. Nada. Niente. Rien. Nichevo.
It is worth noting that this was introduced to me by a friend who had no prior experience with GNU/Linux because the software he requires professionally is only available under Windows. But he is using it now for Internet access. Pretty easy to understand. I like Firefox, too.
OK, so I admit, I haven't gone surfing with it just yet. But is it ever a powerful recovery tool! I like Tom's Boot Disk, which is on the Ultimate Boot CD along with quite a few other useful tools. But you have to experience what this thing can do.
Perhaps it should be pointed out that this is based on Debian and the kernel is a bit old, 2.4.29. But so what? There aren't too many exploits possible if there is nowhere to store anything. And nothing unusual to look at.
Once you boot, you are given a gui — user, not root — under X11 and options to do things needed to surf. That's it. No hard drive. Everything you need to access the Internet and not a single thing more.
However — this is Linux after all — there are the other virtual terminals. All already logged in as root.
Very quickly I was able to put together a simple script with which to establish a network connection. And mounting a drive or partition is no biggey — Knoppix has /etc/fstab all set up for us, mount-points for every single formatted partition.
During the time I needed to use it, the only things I really missed were Midnight Commander and netcat. Apparently netcat is entirely self-contained because there was no no trouble running it copied from a floppy, copied there from SuSE 8.0. On the fly (and without SSH) over the network "cp -R" along with netcat had to substitute for "mc".
Knoppix seems to deal fairly well with "mature" hardware. While X11 baled out on the Pentium 166 with 32 MB, I didn't want to surf on it anyway. And several command-line interfaces as root anywhere is nirvana!
I ought to mention that I was unable to boot the 5-year-old Toshiba notebook (AMD K-5) from the CD. There are numerous options one can enter at boot but none of them helped. My guess is that there is something wrong with a file needed only for the notebook — repeated read errors on one specific block. Proprietary that they are, notebooks are notoriously difficult to configure and deal with anyhow, so no real surprise and not particularly important to me.
Ignoring its original intent, this is a wonderful tool for disaster recovery with both network and mountable devices on which to rescue data. You likely will still want whatever tools you have collected over time to diagnose things like hardware problems. And we're root, so we still do need to be extremely careful about what we do. I had no trouble using fdisk to re-format our nephew's second hard drive and allocate partitions.
The way the people who put this together went about it was very impressive. Instead of hard-wiring everything in, they made skillful use of soft-links. Once I noticed that /etc/hosts etc. were soft-links, it didn't take long to do a script on a floppy to copy what I really wanted from it to /tmp, remove the links and replace them with references to the files in /tmp.
All that was necessary to set up networking was to copy /etc/hosts, /etc/hosts.allow and /etc/hosts.deny from one machine to diskette and then shut it down while our nephew was here and his machine was attached to the network. No long-term approach, but effective in haste.
I looked at the contents of /bin, /sbin, /usr/bin, and /usr/sbin and it would seem that this is a fairly complete Linux distribution: a couple of shells, lilo, miscellaneous mkfs*, awk, sed, ipchains, iptables and so forth. Almost nothing in the way of daemons, window managers or bells-and-whistles, as if anyone should care in the intended environment. Since this CD isn't even half full, you might want to check for your favorite programs before producing your own.
The version I was given was in German but included texts for English prompts at boot. It looks like it ought to be pretty straight-forward to rename two files in order to change to English before burning a CD. And they might serve as patterns for other languages. Pure speculation.
[The ISO image for Knoppix version 3.8.1-2005-04-08 (the latest as of 05 May 2005) is almost 690 MB - not much space for additions! See the mirrors page to download the latest version in several languages. — dsrich]
So our nephew brought his PC over and we connected it to the LAN. Between that and a USB-stick we were able to recover about 90 percent of the stuff he hadn't backed up properly from a drive that seems to have developed a heat-allergy leading to read errors — this drive also had operating system. When all was said and done, he was pretty impressed with what I was able to do.
But was I ever impressed with Knoppix!
If you decide to use this software for Internet access, do be aware of the significance of those root sessions — without password! The only services available are printer and monitor. /etc/hosts and friends are tightly locked down. But it was extremely easy for me to open up network access.
So if some SOB somehow can get some sort of attachment past you and executed... Certainly an unlikely eventuality given the target — not the universe of PCs, not even GNU/Linux, just a variety of a specialized version of Linux. But maybe root should have a password before you burn your own copy.
[A book that discusses this and other Knoppix uses is Knoppix Hacks by Kyle Rankin — dsrich]
Edgar is a consultant in the Cologne/Bonn area in Germany.
His day job involves helping a customer with payroll, maintaining
ancient IBM Assembler programs, some occasional COBOL, and
otherwise using QMF, PL/1 and DB/2 under MVS.
(Note: mail that does not contain "linuxgazette" in the subject will be
rejected.)
Do you want a bit more "humanized" version of your computer? If you are ready for this adventure, all that you need is a computer with Linux operating system and a little bit of time to download and install the required programs. Now let us have some fun with bash and Festival TTS (Text To Speech) software.
I am using a Pentium 4 (1.6 GHz) machine with 128 MB of RAM and Redhat Linux 9 installed. The system has an onboard soundcard, which is quite sufficient for this venture. If you want some privacy with your system, I would also recommend a pair of headphones.
The software that we are going to use is the Festival speech synthesis system — a Text to Speech program developed by the University of Edinburgh. The power of shell scripting can harness the full potential of the Festival program. Festival comes bundled with Redhat 9 and Fedora distributions. If you don't have it installed, you can download it from http://www.cstr.ed.ac.uk/downloads/festival/1.95/ or install from its rpm package using the usual rpm command.
Just like every C language book begins, let us start with a "Hello World" program. For this type
echo "Hello World"| festival --tts
at the command prompt. If everything is working, we should hear "Hello World" through the speakers.
Now let's write a script to play something like "Good morning Sir" whenever we log on to the system. The sound output will dynamically change based on the login time. The shell script goes like this:
#!/bin/bash dat=`date +%H` morning=12 afternoon=15 evening=24 if [ $dat -le $morning ] then echo "Good morning sir" |festival --tts elif [ $dat -gt $morning ] && [ $dat -le $afternoon ] then echo "Good afternoon sir"|festival --tts elif [ $dat -gt $afternoon ] && [ $dat -le $evening ] then echo "Good evening sir"|festival --tts fi
Save this file as salute.sh
in your home directory,
then edit .bash_profile
in your home directory and add
. ~/salute.sh
to it.
Now whenever you login to your system, you will hear the "sweet
salute."
Festival can be used along with the cron to create a personal
assistant who reminds you about your appointments. Cron is used to
schedule programs in Linux. If it is not already running, start the
cron deamon by running service crond start
as root.
Now create your sound alerts — put the following lines into
tea.sh in your home directory:
#!/bin/bash echo "Don't forget to drink tea at 6.30 "| festival --tts
Now schedule this as a job in the cron with specified date and
time. To remind you of this every day at 6.30 P.M , create a file
and name it test
. In it insert the line given
below
30 18 * * * sh ~/tea.sh
and run the command
crontab test
to schedule the event. To check that the job is correctly
scheduled, run crontab -l
. The system will speak the
message at the specified time. You could even program your parents
PC to wish them happy birthday and surprise them.
Curious to know what is happening around the world? You can create a News reader to fetch the hot news from the BBC world website and read it for you. For this purpose, we are going to use the RSS feed of that website.
Really Simple Syndication (RSS) is a technology for sharing information on the web. It simple and well-established XML format used to syndicate headlines. Once a website creates an RSS file they have created a means to allow others to retrieve their headlines. Popular news sites like Yahoo!, BBC News, The New York Times along with tens of thousands of personal blogs and independant media sites all publish RSS feeds that we can use.
This shell script will fetch the RSS feed from the BBC World website and then process its headlines and contents. The output is then piped to the Festival program so we can hear the hottest news happening around the world.
#!/bin/sh #Shell script to fetch and read the hottest news from BBC world using Festival #Here we specify the url url="http://news.bbc.co.uk/rss/newsonline_uk_edition/world/rss.xml" #specify the proxyserver here, if you have one proxy="151.8.18.40:6588" headarg="-10" # default is five headline, change it to increase the no of feeds #specify the proxy with -x option in curl program, if you #don't use one, then remove the '-x "$proxy"' part curl --silent -x "$proxy" "$url" | grep -E '(title>|description>)' | \ sed -n '4,$p' | \ sed -e 's/<title>//' -e 's/<\/title>//' -e 's/<description>/ /' \ -e 's/<\/description>//' | \ #Here we pump the output to Festival head $headarg | fmt|festival --tts exit 0
Save the code as rss.sh
and run it as
sh rss.sh
Make sure that you are connected to internet before running this code,
since the curl
program needs to contact the bbcworld website
and fetch the contents.
Sometimes I wish I could hire somebody to read me books or boring man pages. Nowadays I don't read man pages — I just listen to them! For example, to hear the man page of cron:
man cron | festival --tts
Curious to know the name of people logged on to your system?
who | awk " print {$1};"| festival --tts
There are lots of things you can have read to you - give them a try!
The power of Festival combined with shell scripting is huge — the sky is the limit.
I haven't discussed the theory behind the text to speech as it is out of the scope of this article. If you are curious, visit http://fife.speech.cs.cmu.edu/festival/manual-1.4.1/festival_toc.html for further details.
To learn more about Shell scripting, check out:
Linux Shell Scripting with Bash by Ken O. Burtch
Wicked Cool Shell Scripts by Dave Taylor
Maxin B. John works for HCL Infosystems Ltd, Pondicherry and is an MCA
graduate from Govt. Engg. College, Thrissur. He likes to experiment with Python
and Bash. He thanks his guru Mr. Pramode C.E for introducing him to the
wonderful world of Linux.
Linux 2.4.x had the Logical Volume Manager (LVM) and other multi-disk/multi-partition block device constructs. These have been enhanced by the Device Mapper in Linux 2.6.x. Here is a one line summary:
You can choose any sequence of blocks on a sequence of block devices and create a new block device some of whose blocks are identified with the blocks you chose earlier.That'll take a while to chew on. Meanwhile here are some ways you can use the device mapper:
In Unix, everything is a file. Even a block device like
/dev/hda2
which is meant to be read in
“chunks” called blocks, can be read
byte-by-byte like a file. The loop device allows us to reverse this
asymmetry and treat any file like a block device. Activate loop
devices for your Linux with modprobe loop
(as root) if
necessary.
To demonstrate this without risking serious damage to useful files, we will only use empty files. First of all, create an empty file like so:
dd if=/dev/zero of=/tmp/store1 bs=1024 seek=2047 count=1This creates a file full of nothing and 2 Megabytes in size. Now we make it into a block device:
losetup /dev/loop1 /tmp/store1We then operate with this block device just as we would with any other block device:
blockdev --getsize /dev/loop1
mke2fs /dev/loop1
mount /dev/loop1 /mnt
/mnt
just as you would any
other file-system - the changes will be written to
/tmp/store1
. When you get tired of playing with the
loop blocks, you put them away with commands like losetup -d
/dev/loop1
.
We will use loop devices like /dev/loop1
,
/dev/loop2
and so on as the building block devices in
what follows.
...said the device mapper to the block device. If it is not
already activated, load the device mapper for your Linux with
modprobe dm-mod
(as root.) The device mapper can take
any block device under its wing with a command like
echo 0 $(blockdev --getsize /dev/loop1) linear /dev/loop1 0 | \ dmsetup create newThis creates a “new” block device
/dev/mapper/new
; but this is not really new data.
Reading from this block device returns exactly the same
result as reading directly from /dev/loop1
; similarly
with writing to this block device. Looks a lot like the same old
blah in a new block device! So you could get rid of this block
device by dmsetup remove new
.
Of course, you can do things differently. For example, you can
take only half of /dev/loop1
as your block device:
SIZE1=$(blockdev --getsize /dev/loop1) echo 0 $(($SIZE1 / 2)) linear /dev/loop1 0 | \ dmsetup create halfThe remaining half (which could be the bigger “half” if
/dev/loop1
is odd-sized!) is then also available for
use. You could use it in combination with /dev/loop2
to create another block device:
REST1=$((SIZE1 - $SIZE1 / 2)) echo 0 $REST1 linear /dev/loop1 $((SIZE1 / 2)) > /tmp/table1 echo $REST1 $(blockdev --getsize /dev/loop2) \ linear /dev/loop2 0 >> /tmp/table1 dmsetup create onenahalf /tmp/table1Let us try to understand this example and what each of the three numbers on each line of
/tmp/table
mean. The first
number is the starting sector of the map described, the second
number is the number of sectors in the map. The word
linear
is followed by the name of the original device
that the map refers to; this is followed by the sector number of
the first sector (of this original device) which is assigned by
this map. Read that again!
So you can slice and splice your disks as you like - but there is a small cost, of course. All operations to these new block devices go through the device mapper rather than directly to the underlying hardware. With efficient table management in the kernel, this overhead should not slow down things perceptibly.
Notice how I slipped in (clever me!) the use of
“tables” that contain the mapped device descriptions.
If you are planning to use mapped devices a lot and don't want to
forget your settings, such tables are the way to go. Don't worry -
you can always get the table of any device like
/dev/mapper/new
by
dmsetup table newIn the output, the original block device will appear as
major:minor
, so you will have to figure out what the
device is actually called if you need the table in human readable
form. (Hint: Try
ls -l /dev | grep "$major, *$minor"or something very like it.) Don't forget to run
dmsetup remove half dmsetup remove onenahalfwhen you are through.
Perhaps you are one of those people who own multiple disks configured so that reading n bytes from one of them is slower than reading n/2 bytes from two of them; this may happen because your disk controller is capable of multi-disk operations in parallel or because you have multiple disk controllers. The device mapper can help you to speed up your operations.
SIZE=$(( $(blockdev --getsize /dev/loop1) + \ $(blockdev --getsize /dev/loop2) )) echo 0 $SIZE striped 2 16 /dev/loop1 0 /dev/loop2 0 | \ dmsetup create tigerNow reads/writes from
/dev/mapper/tiger
will alternate
(in 16 sector chunks) between the two devices; you will also have
combined the disks into one as in the linear
case.
There may be a number of reasons why you may want to stop all writes to your block device but not want the system to come to a grinding halt.
modprobe dm-snapshot
if necessary.
Let us start then with a device which is managed by the device mapper. For example it could be created by
SIZE1=$(blockdev --getsize /dev/loop1) SIZE2=$(blockdev --getsize /dev/loop2) cat > /tmp/table2 <<EOF 0 $SIZE1 linear /dev/loop1 0 $SIZE1 $SIZE2 linear /dev/loop2 0 EOF dmsetup create base /tmp/table2Now assume that you have put a file system on this device with a command like
mke2fs /dev/mapper/base
; and suppose you
have begun using this file system at /mnt
with the
command mount /dev/mapper/base /mnt
.
We will now take a “snapshot” of this file-system - in slow motion! The following steps have to be run quite quickly (say with a script) on a running system where this file-system is being changed actively.
First of all you create a duplicate of this device. This is not
just for safety - we will be changing the meaning of
/dev/mapper/base
without telling the file-system!
dmsetup table base | dmsetup create basedupNext we prepare our COW (copy-on-write) block device by making sure the first 8 (or whatever you decide is your chunk size) sectors are zeroed.
CHUNK=8 dd if=/dev/zero of=/dev/loop3 bs=512 count=$CHUNKNow we suspend all I/O (reads/writes) to the
base
device. This is the critical step for a running system. The kernel
will have to put to sleep all processes that attempt to read from
or write to this device; so we want to be sure we can resume soon.
dmsetup suspend base && TIME=$(date)The next step is to use the COW to clone the device:
echo 0 $(blockdev --getsize /dev/mapper/basedup) \ snapshot /dev/mapper/basedup /dev/loop3 p 8 | \ dmsetup create topWhat this says is that from now on reading from
/dev/mapper/top
will return the data from
/dev/mapper/basedup
unless you write
“on top” of the original data. Writes to
top
will actually be written on
/dev/loop3
in chunks of size 8 sectors. If you have
used multiple transparent plastic sheets one on top of the other
(or “Layers” in GIMP) the effect is similar - what is
written on top obscures what is below but wherever nothing is
written on top you see clearly what is written on the lower layer.
In particular, we can now make sure that all changes to the underlying block devices are “volatile.” If we execute the following commands (we'll bookmark this as 'Point A' for later use) -
dmsetup table top | dmsetup load base dmsetup resume basewe will have replaced the file-system under
/mnt
with
another one where all changes actually go to
/dev/loop3
. When we dismantle this setup,
/dev/loop1
and /dev/loop2
will be in
exactly the state that they were in at time
$TIME
.
If /dev/loop1
and /dev/loop2
are on
non-writable physical media (such as a CDROM), whereas
/dev/loop3
is on a writable one (such as RAM or hard
disk), then we have created a writable file-system out of a
read-only one!
This solves the last problem in our list above - but what about
the first two? To tackle the second problem we must have some way
of comparing the new file-system with the older one. If you try to
mount /dev/mapper/basedup
somewhere in order to this,
you will find that Linux (the kernel!) refuses to let you do this.
Instead we can create yet another device:
echo 0 $(blockdev --getsize /dev/mapper/basedup) \ snapshot-origin /dev/mapper/basedup | \ dmsetup create originYou can now mount
/dev/mapper/origin
somewhere (say
/tmp/orig
) and compare the original file system with
the current one with a command like
diff -qur /tmp/orig /mntWhat happens if you write to
/tmp/orig
? Check it out
and you'll be mystified for a moment.
The analogy of plastic sheets breaks down here! All writes to
/tmp/orig
go directly to the underlying device
basedup
but are negated on
/dev/loop3
so as to become invisible to reads from
/mnt
. Similarly, reads from /tmp/orig
ignore whatever changes were made by writing to /mnt
.
In other words the original file system has been forked
(and orthogonally at that!) and /dev/loop3
actually
stores both negative and positive data in order to achieve this. No
plastic sheet can be made to work like this!
To see why this is useful, let us see how it solves the problem of backups. What we want is to get a “snapshot” view of the file-system but we want to continue using the original system. So in this case we should not run the commands at point A above. Instead we run the commands here, at point B:
dmsetup table origin | dmsetup load base dmsetup resume baseNow all writes to
/mnt
will go onto the original
device, but these changes are negated on
/dev/mapper/top
. So if we mount the latter device at
(say) /tmp/snap
, then we can read a snapshot of the
files at time $TIME
from this directory. A command
like
cd /tmp/snap find . -xdev | cpio -o -H new > "backup-at-$TIME"will provide a snapshot backup of the file-system at time
$TIME
.
We could also have taken such a snapshot at Point A with the commands
cd /tmp/orig find . -xdev | cpio -o -H new > "backup-at-$TIME"The main difference is that the changes to
/dev/mapper/top
are volatile! There is no way to
easily dismantle the structure created under (A) without losing all
the changes made. In the backup context you want to retain
the changes; at Point B you run
dmsetup suspend base dmsetup remove top dmsetup remove origin dmsetup table basedup | dmsetup load base dmsetup resume baseand you are back to business as usual. If you were to run this at Point A the results would be quite unpredictable! What would be the status of all those open files on
/dev/mapper/top
? A number of hung processes would be
the most likely outcome - even some kernel threads could hang - and
then perhaps break!
Say you have a laptop or CD which carries some valuable data - valuable not just to you but to anyone who has it. (When, Oh! When will I ever get my hands on such data). In this case backups are no good. What you want is to protect this data from theft. Assuming you believe in the strength of current encryption techniques you could protect it by encrypting the relevant file. This approach has some serious problems:
modprobe dm-crypt
if necessary. Also activate some
encryption and hashing mechanism by commands like modprobe
md5
and modprobe aes
if necessary.
First of all you need to generate and store your secret key. If you use AES as indicated above then you can use a key of length up to 32 bytes which can be generated by a command like
dd if=/dev/random bs=16 count=1 | \ od --width=16 -t x2 | head -1 | \ cut -f2- -d' ' | tr -d ' ' > /tmp/my_secret_keyOf course, you should probably not output your secret key to such a file - there are safer ways of storing it:
gpg
or openssl
and
then store it on a the USB stick or a device that never leaves
you.You can now setup the encrypted device
echo 0 $(blockdev --getsize /dev/loop1) \ crypt aes-plain $(cat /tmp/my_secret_key) 0 /dev/loop1 0 | \ dmsetup create mydataYou can then make a file-system
mke2fs
/dev/mapper/mydata
on this block device and store data on it
after mounting it somewhere with mount /dev/mapper/mydata
/mnt
. All the data written to /mnt
will then be
transparently encrypted before storing it in
/dev/loop1
. When you are through you unmount the
device and dismantle it as before:
umount /mnt dmsetup remove mydataThe next time you want to use the device you can set it up with the same command as above (providing you supply the secret key in
/tmp/my_secret_key
). Of course, you shouldn't rune
mke2fs
on the device a second time unless you want to
erase all that valuable data!
All the steps given above can be carried out on any block device(s) in place of the loop devices that were used. However, when the block device is the root device then life gets a little more complex. (Roots generally are complex).
First of all we need to put the root device under the control of
the device mapper; this is best done with an initial RAM disk (or
initrd
). Even after this is done, we need to be
careful if we are trying to run some of the above commands for the
root file system on a “live” system. In particular, it
is not advisable to suspend I/O on the root file system without
deep introspection! After all this means that all processes that
make a read/write call to the root file system will be put to
sleep.
Here is one way around the problem. Create a temporary file system
mount -t tmpfs tmpfs /mntTo this file system copy all the files that are necessary in order to perform the changes - in particular, you need
/sbin/dmsetup
, /bin/sh
, the
/dev
files and all shared libraries that these
programs depend on. Then you run chroot /mnt
. After
this you can run a script or (if you type quickly and
without errors!) a sequence of commands that will suspend the root
device map and make relevant changes to it - for example, to take a
snapshot. Don't forget to resume the root device before exiting the
chroot
.
Given the complexity of the various operations, it is probably best to produce a shell script or even a C program that carries out the tasks. Luckily, the latter has already been implemented - the Linux Logical Volume Manager version 2 does carry out most of the tasks described above quite “automagically.” Setup and use of encryption is greatly simplified by the cryptsetup program. Why then did I write this article?
I originally came upon dmsetup while
trying to create a read-only root file system for a
“live” CDROM. Unfortunately, the LVM2 tools are not
useful as they only look at the use of snapshots for backups -
clearly they don't care for COWs! The only resource that I found
for this was the RedHat
Mailing list archives. There are now tools which come with live
CD's that make use of dmsetup
; for example I came
across this link
which explains how UBuntu does it.
Of course, using dmsetup
allowed me to get as
“close to the metal” as is possible without writing
real programs...
This document was translated from LATEX by H EVEA.
Kapil Hari Paranjape has been a ``hack''-er since his punch-card days.
Specifically, this means that he has never written a ``real'' program.
He has merely tinkered with programs written by others. After playing
with Minix in 1990-91 he thought of writing his first program---a
``genuine'' *nix kernel for the x86 class of machines. Luckily for him a
certain L. Torvalds got there first---thereby saving him the trouble
(once again) of actually writing code. In eternal gratitude he has spent
a lot of time tinkering with and promoting Linux and GNU since those
days---much to the dismay of many around him who think he should
concentrate on mathematical research---which is his paying job. The
interplay between actual running programs, what can be computed in
principle and what can be shown to exist continues to fascinate him.
By S. Keeling
This describes my experiences in transitioning from a homebuilt iptables firewall scriptii to "Arno's iptables-firewall" (AIF)v, from Arno van Amersfoort (). AIF can produce a robust iptables based firewall, even when wielded by a relative newcomer to iptables firewalls. The time between reading the documentation and dropping it into place could be as little as an hour.
AIF is described in Arno's README as "Arno's iptables firewall - Single- & multi-homed firewall script with DSL/ADSL support". It is (C) Copyright 2001-2005 by Arno van Amersfoort. It's free software, licenced under the GNU General Public License.
If you decide you want to try using this, I strongly recommend you READ THE FAQ on Arno's website, especially if you join the mailing list in hope of support. Arno points out in there that if you haven't done so, your pleas for assistance will be cheerfully ignored until you do.
Of course, considering this is the Twenty-first Century:
I AM NOT ADVISING YOU TO DO THIS! IF YOU DO THIS AND IT BREAKS SOMETHING, YOU GET TO KEEP BOTH PIECES. I EXPRESSLY, AND VIGOROUSLY, DENY ANY RESPONSIBILITY FOR ANY NEGATIVE RESULTS YOU OR ANYONE ELSE MAY SUFFER FROM YOUR HAVING DONE THIS. THE FOLLOWING IS WRITTEN FOR ITS ENTERTAINMENT VALUE ONLY! TELL YOUR MOTHER YOU'RE ABOUT TO DO THIS PRIOR TO DOING IT.
[fscking lawyers (no, that's not a typo)... Sorry for shouting.]
When I started writing this, I was working with version 1.8.2, which is apparently over a year old. At Arno's suggestion, I've since upgraded to the latest release, version 1.8.3-RC3 (April 9, 2005). So, if I've missed anything important in updating this, that's why it may appear confused. Certain example listings were left alone, but I've tried to cover the important bits of the latest version.
Some of Arno's comments on my original article are as follows:
Thanks for the article. I like it a lot.
May I suggest to have a look at the latest 1.8.3RC3 (instead of 1.8.2a
stable, which is over 1 year old)? It has a lot (and I mean A LOT)
[of] improvements like:
1.8.4-stable
, with even more improvements, will
be out soon.
Nice guy, that Arno. When I started on this, I (mis)corrected his usage of "DRDOS" to "DDoS" (or "Distributed Denial of Service"xi), and that was the wrong thing to do. He actually means "Distributed Reflection Denial Of Service", something I'd never heard of. I took his advice. For me, just getting config files with eighty character long lines is a terrific improvement.
Many thanks to the helpful and patient staff at LG for all their support in producing this article, and the same to Arno van Amersfoort for having made any of it possible.
My situation is this (which is not to suggest you need to be doing something similar):
Previously, I'd used a handcrafted set of iptables commands which pretty much ruthlessly, and blindly, locked everything out through sheer brute force. Anything the firewall saw that wasn't connected to an ESTABLISHED or RELATED IP process previously initiated by my actions, was simply logged and dropped.
This is generally not difficult to do, but at times, it is. How to let NTP servers' replies back in? I struggled with that for months. Googling for help on that produced so many conflicting examples (some of which worked, some not), it was infuriating. I was always on the lookout for an alternative. I wanted something somewhat like my existing setup, but more robust, more suspicious, more dynamic, and smarter overall about networking than I am.
Over the years, I've tried things others suggested, but they always seemed a bit wrong. I don't want the thing to fire up an X Window GUI forcing me to point and click my way through the configuration. If I already knew everything there was to know about TCP/IP and networking, that might be helpful, but I don't. Besides, that's just not how I do things. I want something with few moving parts, all of which have their own home directories, and which can be expected to stay there. I don't want the thing to fail some morning because somebody changed some obscure library I'd never heard ofvi.
On "Sun Jan 9 12:18:45 MST 2005"i, I found mention of "Arno's iptables-firewall" (AIF). Now that I've finally taken some time to get it working and try it out, I'm happy to say it appears to be just what I was looking for. Arno's system is intended for far more complicated setups than my own (for instance, it supports NAT and VPNs), but it easily scales down to my needs. It thinks of an external (connected to the internet) and an internal (LAN) interface. In fact, the latest release has been updated to handle multiple external interfaces.
It's not difficult. You should be able to get the mechanics of this done in half an hour, depending on how careful you want to be. Budget an hour for the job since there's some reading to do beforehand.
Go to his download page and grab it. It's ~54 kilobytes. It'll be in
the form of a tarball (gzipped tar archive). cd
to somewhere
safe, make a new directory to hold it, and extract it:
cd mkdir ~/dwn cd ~/dwn tar xzf /path/to/arno-iptables-firewall-1.8.3-rc3.tgz
That creates a new directory, ~/dwn/arno-iptables-firewall-1.8.3-RC3:
total 276 drwxrwxr-x 2 keeling keeling 4096 Apr 9 06:20 ./ drwxr-xr-x 27 keeling keeling 4096 Apr 18 10:50 ../ -rw-r--r-- 1 keeling keeling 20063 Apr 9 06:20 CHANGELOG -rwxr-xr-x 1 keeling keeling 13580 Apr 9 06:20 fwfilter* -rw-r--r-- 1 keeling keeling 18010 Apr 9 06:20 gpl_license.txt -rw-rw-r-- 1 keeling keeling 1467 Apr 9 06:20 iana-reserved-nets.txt -rw-rw-r-- 1 keeling keeling 31674 Apr 9 06:20 iptables-firewall.conf -rw-r--r-- 1 keeling keeling 29755 Apr 9 06:20 iptables-firewall.conf.example -rwxr-xr-x 1 keeling keeling 112070 Apr 9 06:20 rc.iptables* -rw-r--r-- 1 keeling keeling 16887 Apr 9 06:20 README -rw-r--r-- 1 keeling keeling 2318 Apr 9 06:20 syslog.conf.Debian -rw-r--r-- 1 keeling keeling 1202 Apr 9 06:20 syslog.conf.RedHat
They're all flat ASCII text files. Now, read the README. It starts out by mentioning it's free software, licenced under the GNU General Public License. It goes on to explain what the various files are for. One of the most welcome things to me in the latest version is Arno has chopped the line length in most of his stuff to a much more readable eighty characters or so. He appears to like lines that are about a hundred characters long, and displaying them in an eighty character wide xterm (or console) made them very difficult to read. Mostly, that's no longer a problem. You'll still see remnants of this, in his actual firewall script for example.
Following the file descriptions, he lists "Some IMPORTANT (security) information". Following that is a "Quick setup" section, a section on WHAT TO DO IN THE CONFIG FILE, and some info you may need in rebuilding your kernel if it doesn't already have iptables support (:-O really?!? I haven't seen any distributions supplying pre-compiled kernels without iptables support, or maybe this is in case you're having trouble rolling your own... I'll have to go back and re-read that bit sometime).
The old version flatly refused to work if you were using a 2.2.x kernel and ipchains. The latest version detects 2.2.x and ipchains and continues (I haven't tested this).
The README used to suggest installation instructions you might use, but perhaps he's blended those into the other sections? I notice there's also a bit at the top of the firewall script itself. However, I suggest you use common sense and figure out how you need it done for your system. They're just a couple of scripts and config files. How difficult can it be? :-)
On the other hand...
As root:
$ cp rc.iptables /etc/init.d $ vi /etc/init.d/rc.iptables
A few lines into the file, you'll see CONFIG_FILE. Change that to say:
CONFIG_FILE=/etc/firewall/iptables-firewall.conf
Now make it executable (Arno suggests this should be 700; you decide):
$ chmod 744 /etc/init.d/rc.iptables
If necessary:
$ chown root:root /etc/init.d/rc.iptables
Now make a home for the config file(s):
$ mkdir /etc/firewall $ chmod 755 /etc/firewall $ cp iptables-firewall.conf /etc/firewall $ chmod 600 /etc/firewall/iptables-firewall.conf $ vi /etc/firewall/iptables-firewall.conf
If you're going to use them, you now want to create iptables-blocked-hosts, iptables-custom-rules, and iptables-mac-addresses (make sure those are the names mentioned, down at the bottom, in the config file). I notice they're commented out in the latest version's config file. These need to be at least one blank line long, so vi them, insert a carriage return, save, and exit.
Now go back to the top of iptables-firewall.conf, inserting the important stuff telling AIF how it should do things for your system. This part gets a little hairy, so you might like to peruse the mailing list archives to see if you can find explanations of how to do this correctly. The FAQ also mentions a few little syntactical nits that it might help to know. I went with Arno's suggestion and changed as little as I could. There are lots of comments explaining what things do and when you might want to use them.
Yes, that is a little vague. Sorry, but this bit is the so-called kernel of what you need to learn about iptables for AIF to work for you the way you want it to work. What is it you want to do, and what is there that you have to work with? DSL/ADSL? Dialup ppp? WiFi from a broadband modem? What ports do you want to open up to the crackers? Do you know what you're doing with iptables, or are you a dilettante like me?
You do want to tell it what your external interface is:
EXT_IF="ppp+"in my case ("ppp+" covers ppp0, ppp1, ppp2, etc.) Then:
INT_IF="eth0"takes care of my NIC along with:
INTERNAL_NET="192.168.1.0/24"
One of the things mentioned in the FAQ is you don't want or need "127.0.0.1" (the loopback interface) mentioned anywhere. "Ah, so I guess I don't need to do anything about my caching nameserver? Uhh..." Well, the MaraDNS man page has a good section on this. Later.
Also, you might like to take my chmod commands above with a grain of salt. I don't see a great deal of point in locking things down so group and other can't read them. However, that is how Arno suggests they be. You make up your own mind. To me, if a config file doesn't contain any sensitive information, it's a little silly to make it owner:group read-only.
Once you've solved the config file problem, you then need to figure out how you want it executed. If you want it to come up at boot time, you'll need init script links in /etc/rcN.d directories. Arno mentions how to do this at the top of the firewall script itself. You can do it by hand, but most distributions have some sort of tool you can use to manage those links.
For my purposes, I wanted it controlled by interface initialization, and that fits well with Debian's /etc/ppp/ip-up.d/ system. Any script in that directory will be run when the interface is brought on line and configured. There's also /etc/ppp/ip-down.d/ which works similarly in reverse.
Now, take a look in /etc/network. Just like ppp, there are if-up.d "-ish" (among others) directories in there too.
In my case, I created the script /etc/ppp/ip-up.d/00iptables_firewall. It needs only two lines: the "shebang", and a line to call rc.iptables:
#!/bin/sh /etc/init.d/rc.iptables start
Now, "chmod 744 /etc/ppp/ip-up.d/00iptables_firewall". Similarly, you need a script in /etc/ppp/ip-down.d that will take the firewall down when the interface goes down:
#!/bin/sh # if [ ! "$(/sbin/ifconfig | /bin/grep eth0)" ]; then /etc/init.d/rc.iptables stop # fi
Notice the commented out lines. When I started on this, that did a sanity check first: if, by chance, I happen to have both ppp0 and ethN up and connected, it would be a little silly to take down the firewall if only one of the interfaces was being taken down. However, now that I think about it, that might be a little dumb. I'm still re-thinking that bit.
Make sure that file's executable too.
The last thing you might want to do is tweak /etc/syslog.conf to tell syslogd to send firewall related messages to /var/log/firewall. In the latest version, this is optional. Arno was kind enough to include a couple of examples of syslog.conf that you can work with. I just did this: look for the first instance of "kern.*" and change that to "kern.!=debug", then add a new line that points kern.=debug at /var/log/firewall. Now, I have:
auth,authpriv.* /var/log/auth.log *.*;auth,authpriv.none -/var/log/syslog #cron.* /var/log/cron.log daemon.* -/var/log/daemon.log kern.!=debug -/var/log/kern.log lpr.* -/var/log/lpr.log mail.* -/var/log/mail.log user.* -/var/log/user.log uucp.* /var/log/uucp.log # Logging for iptables kern.=debug -/var/log/firewall
Once you change /etc/syslog.conf, you need to touch the new logfile (only do this if it doesn't already exist):
$ touch /var/log/firewall
and you need to cycle syslogd to make it re-read its config file:
$ kill -HUP $(pidof syslogd)
If you don't have "pidof", you'll have to determine syslogd's PID and insert that there instead. "ps fax | grep syslogd" says this:
(0) keeling /home/keeling_ ps fax | grep syslogd 242 ? S 0:00 /sbin/syslogd 30307 pts/2 S 0:00 | \_ grep syslogd
so you need to say "kill -HUP 242"
If you've done the syslog.conf fiddle, make sure you've set "FIREWALL_LOG=/var/log/firewall" and "LOGLEVEL=debug" in /etc/firewall/iptables-firewall.conf. Hopefully, you have logrotate on your system, else the log file will just grow and grow, eventually filling your filesystem.
This is "/etc/logrotate.d/firewall":
/var/log/firewall { rotate 7 daily compress notifempty create 0640 root adm delaycompress create }
Now, you should be good to go. I would suggest the first (few?) time(s), you should run /etc/init.d/rc.iptables by hand ("chmod 644 /etc/ppp/ip-up.d/00iptables_firewall" first, bring up the connection, then run "/etc/init.d/rc.iptables start"). It spits out quite a few messages mentioning what it's doing. You should peruse that output (see the example below), ensuring it's doing what you want. This is also when you'll get a chance to do something about any errors found in the config file. "iptables -nL | less" will show the firewall rules. "tail -f /var/log/firewall" will show you the effect of those rules.
If you can't figure out how to make AIF do something you did before, Arno has thought about that and made exceptions possible. Take the iptables rule you used before and stuff it into iptables- custom-rules. Of course, be warned that this may compromise whatever AIF is attempting to do for you. However, if you were doing it before, you're probably no worse off now than you were.
In my case, when I was using the older version, I had this in my /etc/firewall/iptables-custom-rules to make chrony/NTP work:
# man iptables says using a name that must be resolved via remote # DNS is a Really Bad Idea. Sigh. # iptables -t filter -I INPUT -s 0.pool.ntp.org -m tcp -p tcp --dport 123 -j ACCEPT iptables -t filter -I INPUT -s 1.pool.ntp.org -m tcp -p tcp --dport 123 -j ACCEPT iptables -t filter -I INPUT -s 2.pool.ntp.org -m tcp -p tcp --dport 123 -j ACCEPT
With the new version, however, I've commented those out and used "HOST_OPEN_TCP" in the config file instead:
HOST_OPEN_TCP="0.pool.ntp.org>123 1.pool.ntp.org>123 2.pool.ntp.org>123"
Take a look at what it's doing. Here's an example of rc.iptables output:
Arno's IPTABLES Firewall Script v1.8.3-RC3 --------------------------------------------------------------- Sanity checks passed...OK Detected IPTABLES module... Loading additional IPTABLES modules: All IPTABLES modules loaded! Setting default secure policies. External (internet) interface(s) (EXT_IF) : ppp+ --------------------------------------------------------------- Configuring /proc/.... settings Enabling anti-spoof with rp_filter. Disabling the logging of martians. Disabling the acception of ICMP-redirect messages. Setting the max. amount of simultaneous connections to 4096 (default). Enabling reduction of the DoS'ing ability. Disabling ECN (Explicit Congestion Notification). Using loglevel debug for syslogd. Flushing rules in the filter table. Setting up firewall rules ------------------------- Accepting packets from the local loopback device. Enabling setting the maximum packet size via MSS. Enabling mangling TOS. Logging of INVALID packets enabled. Reading custom IPTABLES rules from /etc/firewall/iptables-custom-rules Logging of ICMP flooding enabled. Setting up INPUT policy for internal interface(s) eth0 Logging of stealth scans (nmap probes etc.) enabled. Logging of packets with bad TCP-flags enabled. Logging of fragmented packets enabled. Logging of access from reserved addresses enabled. Setting up anti-spoof rules. Logging of DHCP broadcasts disabled. Logging of probable "lost connections" disabled. Logging of explicitly blocked hosts enabled. Logging of denied local output connections enabled. Logging of denied LAN (forward) output connections enabled. Packets will NOT be checked for private source addresses. Denying the whole world to send ICMP-requests(ping). Logging of dropped ICMP-request(ping) packets enabled. Logging of dropped other ICMP packets enabled. Logging of possible stealth scans enabled. Logging of (other) connection attempts to PRIVILEGED TCP ports enabled. Logging of (other) connection attempts to PRIVILEGED UDP ports enabled. Logging of (other) connection attempts to UNPRIVILEGED TCP ports enabled. Logging of (other) connection attempts to UNPRIVILEGED UDP ports enabled. Logging of other IP protocols (non TCP/UDP/ICMP) connection attempts enabled. Setting up FORWARD policy for internal interface(s) eth0: Allowing all TCP ports Allowing all UDP ports Allowing all IP protocols Security is ENFORCED for the external interface(s) in the FORWARD chain. (Re)loading list of BLOCKED hosts (blackhole) from /etc/firewall/iptables-blocked-hosts Apr 18 14:47:12 All firewall rules applied.
Woof! You should see the "iptables -nL" output! Some of this stuff, I'd only vaguely heard of. Take a gander into the rc.iptables script itself to see all that it's doing. First, the "Sanity checks", then it modprobes all the necessary kernel modules (again, some of which I'd never heard of). Arno's doing all the obscure:
echo ${some_integer} > /proc/sys/net/blah/blah
that I've never managed to either take the time to understand or find a decent reference for. Finally, he defines various firewall rulesets.
One of the neat things about this is, instead of the fairly bland:
Mar 16 07:24:38 localhost kernel: IN=ppp0 OUT= MAC= \ SRC=xxx.xxx.xx.xx DST=xxx.xxx.xxx.xx LEN=48 TOS=0x00 \ PREC=0x00 TTL=102 ID=59091 DF PROTO=TCP SPT=3946 DPT=6348 \ WINDOW=64240 RES=0x00 SYN URGP=0
I now see things like this:
Apr 6 12:41:06 localhost kernel: Connection attempt (UNPRIV): \ IN=ppp0 OUT= MAC= SRC=xx.xxx.xxx.xxx DST=xxx.xxx.xxx.xx LEN=48 \ TOS=0x00 PREC=0x00 TTL=109 ID=28712 DF PROTO=TCP SPT=4194 DPT=15118 \ WINDOW=65535 RES=0x00 SYN URGP=0
which is pretty slick. It explains what it is it saw. "UNPRIV" means the destination port (DPT) is higher than port 1024 (see /etc/services).
Other interesting stuff:
Apr 18 20:22:42 localhost kernel: Possible DRDOS TCP attempt: \ IN=ppp0 OUT= MAC= SRC=xxx.xxx.xxx.xxx DST=xxx.xxx.xxx.xx \ LEN=576 TOS=0x00 PREC=0x00 TTL=63 ID=48819 DF PROTO=TCP SPT=110 \ DPT=4345 WINDOW=5840 RES=0x00 ACK URGP=0
That came in on pop3/TCP ("grep 110 /etc/services") looking for some port I don't have (4345).
Among the things you get in AIF, Arno includes "fwfilter", a shell script you can use to massage the logfile entries. I'm already running something else called fwlogwatchviii, but I decided to try this anyway. Arno supplies instructions inside the script explaining how it's to be used. I created a short script in /etc/cron.daily/fwfilter:
#! /bin/sh # # /etc/cron.daily/fwfilter - arno's iptables-firewall activity # monitoring script. # FWFILTER=/path/to/arno's/fwfilter FWLOG=/var/log/firewall DAY="$(/bin/date '+%b %e' --date=yesterday)" if [ -f "${FWFILTER}" -a -f "${FWLOG}" ]; then /bin/grep "${DAY}" ${FWLOG} | ${FWFILTER} fi
When the system runs its daily cron jobs, this slurps in the firewall log looking for entries from yesterday, pipes them through to Arno's fwfilter script, and the output is mailed to root. The result is quite pretty and informative. Log file entries are colorized by type. The mutt mail program can show ANSI escape sequence color with "set allow_ansi=yes", but you really ought to see the output in (eg.) rxvt or xterm.
Note, depending on your installed version of awk, you may need to fiddle with the fwfilter script prior to using it. See the variable "AWK_BIN". If "which awk" (or better, "dpkg -l | grep awk", or "rpm -qf $(which awk)") mentions "mawk", you'll need to install gawk for fwfilter to work.
I think it was a success. I haven't lost anything, other than a little time. All the things I could do before, I can still do now. I see log records of other, more esoteric events, that I hadn't noticed before. That's the sort of thing I do want to hear about.
I've since had the chance to drop this into the computer I'm rebuilding for a friend as well. It's worked pretty well, hasn't interfered with the two computers' ability to communicate with each other, and was easy to implement. So far, I've nothing but praise for AIF. It's just what I've been hunting for for a long time.
Arno's system is easy to use, can probably scale to fit any situation, and can do it in the hands of a relative newcomer to firewalls. If you can read, you can benefit from Arno's firewall.
If you do try this, and you like it as much as I do, take his advice in the README and donate to his favourite charities.
Rock on, Arno. Bravo. Thank you very much!
[i] Yes, I do know exactly when it was that I ran across a mention of AIF. I have a short perl script that saves, datestamps, and formats as htmls any cuts+pastes that I do during my surfing activities ( here).
[ii] My script implementing my old, hand-crafted rules is here.
[iii] The official URL for fauxident is: http://www.alcyone.com/software/fauxident/ Its author is Erik Max Francis http://www.alcyone.com/max/
[iv] MaraDNS is by Sam Trenholme http://www.samiam.org
[v] Arno's iptables-firewall: http://rocky.molphys.leidenuniv.nl/ Freshmeat homepage: http://freshmeat.net/projects/iptables-firewall/?topic_id=151 Arno's mailing list: https://lists.btito.net/mailman/listinfo/firewall
[vi] This happened to me with XCDRoast. All of a sudden, I could no longer do backups. That's why I now make my own archives with afio, use mkisofs to stuff them into an ISO image, followed by cdrecord to burn that to a CD.
[viii] fwlogwatch is from Boris Wesslowski , RUS-CERT http://cert.uni-stuttgart.de
[ix] Debian "stable", at this time (Woody), installs with a 2.2.x kernel. iptables demands 2.4 and up, and the old version of Arno's firewall did too. The latest appears to handle either.
[x] AIF thinks external interface (the Internet) and internal interface (your LAN). AIF only armours the external. It doesn't do much of anything to the internal interface other than making sure anything from it is allowed out. So, testing whether eth0 is up before taking down the firewall is likely the wrong thing to do. I've since disabled that test to verify.
[xi] Of course, everyone knows that "DR-DOS" means "Digital Research Disk Operating System" (a la Gary Kildall), right?
In 1990, after about a decade of processing seismic data (first as a
computer operator, then as geophysical technician), I sat down to my first
personal computer and started teaching myself how to program in C. After a
couple of months at it, I decided it would make a fairly challenging and
esthetically pleasing career, so I signed up for a programming course. I
graduated with an A average.
Since then, work has taken me from Grande Prairie, Alberta to Khartoum,
Sudan. I've worked with SunOS, Solaris, HP-UX, AIX, FreeBSD and OpenBSD.
I've worked with many different distributions of Linux (SLS, Slackware,
Debian (twice), Redhat, and SuSE). I generally program in Perl. I
specialize in generic Unix.
By Ben Okopnik
Originally published in Issue 55 of Linux Gazette, May 2000
There are two major products that come out of Berkeley: LSD and UNIX. We don't believe this to be a coincidence. -- Jeremy Anderson
MAILPATH='/usr/spool/mail/bfox?"You have mail":~/shell-mail?"$_ has
mail!"'
(He was immediately hired by an Unnamed Company in Silicon Valley for an unstated (but huge) salary... but that's beside the point.)
<Shrug> What the heck; I've already gone parasailing and scuba-diving this month (and will shortly be taking off on a 500-mile sail up the Gulf Stream); let's keep living La Vida Loca!
The built-in parsing capabilities of "bash" are rather minimal as compared to, say, Perl or AWK; in my best estimate, they're not intended for serious processing, just "quick and dirty" minor-task handling. Nevertheless, they can be very handy for that purpose.
As an example, let's say that you need to differentiate between lowercase and capitalized filenames in processing a directory - I ended up doing that with my backgrounds for X, since some of them look best tiled, and others stretched to full-screen size (file size wasn't quite a good-enough guide). I "capped" all the names of the full-sized pics, and "decapped" all the tiles. Then, as part of my random background selector, "bkgr", I wrote the following:
... # We need _just_ the filename fn=$(basename $fnm) # Set the "-max" switch if the test returns 'true' [ -z "${fn##[A-Z]*}" ] && MAX="-max" # Run "xv" with|without the "-max" option based on the test result xv -root -quit $MAX $fnm & ...
Confusing-looking stuff, isn't it? Well, part of it we already
know: the [ -z ... ]
is a test for a zero-length
string. What about the other part, though?
In order to 'protect' our parameter expansion result from the cold, cruel world (e.g., if you wanted to use the result as part of a filename, you'd need the 'protection' to keep it separate from the trailing characters), we use curly brackets to surround the whole enchilada -
$d
is the same as${d}
- except that
the second variety can be combined with other things without losing
its identity, like so:
... d=Digit # "Digitize" echo ${d}ize # "Digital" echo ${d}al # "Digits" echo ${d}s # "Digitalis" echo ${d}alis ...
Now that we have it isolated from the world, friendless and all alone... oops, sorry - that's "shell script", not "horror movie script" - I lose track once in a while... Anyway, now that we've separated the variable out via the curly braces, we can apply a few tools incorporated in Bash to perform some basic parsing. Note that I'm going to show the result after each 'echo' statement as if that statement had been executed.
### Let's pick a nice, longish word to play with. var="amanuensis" ### ${#var} - return length echo ${#var} 10 ### ${var#word} - cut shortest match from start echo ${var#*n} uensis ### ${var##word} - cut longest match from start echo ${var##*n} sis ### ${var%word} - cut shortest match from end echo ${var%n*} amanue ### ${var%%word} - cut longest match from end echo ${var%%n*} ama ### ${var:offset} - return string starting at 'offset' echo ${var:7} sis ### ${var:offset:length} - return 'length' characters starting at 'offset' echo ${var:1:3} man ### ${var/pattern/string} - replace single match echo ${var/amanuen/paralip} paralipsis ### ${var//pattern/string} - replace all matches echo ${var//a/A} AmAnuensis
(For the last two operations, if the pattern begins with #, it will match at the beginning of the string; if it begins with %, it will match at the end. If the string is empty, matches will be deleted.)
There's actually a bit more to it - things like variable indirection, and parsing arrays - but, gee, I guess you'll just have to study that man page yourself. <grin> Just consider this as motivational material.
So, now that we've looked at the tools, let's look back at the
code -[ -z "${fn##[A-Z]*}" ]
Not all that
difficult anymore, is it? Or maybe it is; my thought process, in
dealing with searches and matches, tends to resemble
pretzel-bending. What I did here - and it could be done in a number
of other ways, given the above tools - is match for a max-length
string (i.e., the entire filename) that begins with an uppercase
character. The [ -z ... ]
returns 'true' if the
resulting string is zero-length (i.e., matches the [A-Z]* pattern),
and $MAX is set to "-max".
Note that, since we're matching the entire string,
${fn%%[A-Z]*}
would work just as well. If that seems
confusing - if all of the above seems confusing - I
suggest lots and lots of experimentation to familiarize yourself
with it. It's easy: set a parameter value, and experiment, like so
-
Odin:~$ experiment=supercallifragilisticexpialadocious Odin:~$ echo ${experiment%l*} supercallifragilisticexpia Odin:~$ echo ${experiment%%l*} superca Odin:~$ echo ${experiment#*l} lifragilisticexpialadocious Odin:~$ echo ${experiment##*l} adocious...and so on. It's the best way to get a feel for what a certain tool does; pick it up, plug it in, put on your safety glasses and gently squuueeeze the trigger. Observe all safety precautions as random deletion of valuable data may occur. Actual results may vary and will often surprise you.
joe= ### ${parameter:-word} - If parameter is unset, substitute "word" echo ${joe:-mary} mary echo $joe ### ${parameter:?word} - Display "word" or error if parameter is unset echo ${joe:?"Not set"} bash: joe: Not set echo ${joe:?} bash: joe: parameter null or not set ### ${parameter:=word} - If parameter is unset, set it to "word" echo ${joe:=mary} mary echo $joe mary ### ${parameter:+word} - "word" is substituted only if parameter is set echo ${joe:+blahblah} blahblah
Let's look at what this might involve. Here's a clip of a notional phonebook to be used for the job:
Name | Category | Address | |
Jim & Fanny Friends | Business | 101101 Digital Dr. LA CA | fr@gnarly.com |
Fred & Wilma Rocks | friends | 12 Cave St. Granite, CT | shale@hill.com |
Joe 'Da Fingers' Lucci | Business | 45 Caliber Av. B-klyn NY | tuff@ny.org |
Yoda Leahy-Hu | Friend | 1 Peak Fribourg Switz | warble@sing.ch |
Cyndi, Wendi, & Myndi | Friends | 5-X Rated St. Holiday FL | 3cuties@fl.net |
Whew. This stuff obviously needs to be read in by fields - word counting won't do; neither will a text search. Arrays to the rescue!
#!/bin/bash # 'nlmail' sends the monthly newsletter to friends listed # in the phonebook # "bash" would create the arrays automatically, since we'll # use the 'name[subscript]' syntax to load the variables - # but I happen to like explicit declarations. declare -a name category address email # A little Deep Hackery to make the 'for' loop read a line at a time OLD=$IFS IFS=' ' for line in $(cat phonelist) do # Increment the line counter ((x++)) # Load up the 'name' variable name[$x]="${line:0:25}" # etc. for 'category', category[$x]="${line:25:10}" # etc. for 'address', address[$x]="${line:35:25}" # etc. for 'email'... email[$x]="${line:60:20}" done # Undo the line-parsing magic IFS=$OLD ...At this point, we have the "phonelist" file loaded into the four arrays that we've created, ready for further processing. Each of the fields is easily addressable, thus making the stated problem - that of e-mailing a given file to all my friends - a trivial one (this snippet is a continuation of the previous script):
... for y in $(seq $x) do # We'll look for the word "friend" in the 'category' field, # make it "case-blind", and clip any trailing characters. if [ -z "${category[$y]##[Ff]riend*}" ] then mutt -a Newsletter.pdf -s 'S/V Ulysses News, 6/2000' ${email[$y]} echo "Mail sent to ${name[$y]}" >> sent_list.txt fi doneThat should do it, as well as pasting the recipients' names into a file called "sent_list.txt" - a nice double-check feature that lets me see if I missed anyone.
The array processing capabilities of "bash" extend a bit beyond this simple example. Suffice it to say that for simple cases of this sort, with files under, say, a couple of hundred kB, "bash" arrays are the way to go.
Note that the above script can be easily generalized - as an example, you could add the ability to specify different phone-lists, criteria, or actions, right from the command line. Once the data is broken up into an easily-addressable format, the possibilities are endless...
Until next month -
Happy Linuxing!
"...Yet terrible as UNIX addiction is, there are worse fates. If UNIX is the heroin of operating systems, then VMS is barbiturate addiction, the Mac is MDMA, and MS-DOS is sniffing glue. (Windows is filling your sinuses with lucite and letting it set.) You owe the Oracle a twelve-step program." -- the Usenet Oracle
The "man" pages for 'bash', 'builtins', 'sed', 'mutt'
"Introduction to Shell Scripting - The Basics" by Ben Okopnik, LG #53 "Introduction to Shell Scripting" by Ben Okopnik, LG #54 "Introduction to Shell Scripting" by Ben Okopnik, LG #55 "Introduction to Shell Scripting" by Ben Okopnik, LG #56
